Appendix 1
Technical Data
Printing
Print Technique
Printhead Resolution
Print Speed (variable)
Print Width (max)
Print Length (max)
Media Width (min/max)
Media Width (min/max)
Media Roll Diameter (max)
Media Roll Core Diameter
Ribbon Width (min/max)
Ribbon Roll Diameter (outer)
Ribbon Roll Core Diameter (inner)
Print Directions
Modes of Operation
Tear-Off (Straight-through)
Peel-Off (Self-strip)
Firmware
Operating System
Smooth Fonts
Built-in bar code symbologies (std)
Physical Measures
Dimensions (W x L x H)
Weight (excluding media)
Ambient Operating Temperature
Humidity
Electronics
Microprocessor
On-board Flash SIMMs
On-board DRAM SIMM
Power Supply
AC Voltage
PFC Regulation
Maximum Power Consumption
64
Direct Thermal (Thermal Transfer as option)
8 dots/mm (203.2 dpi)
100 to 200 mm/sec. (≈ 4 to 8 inches/sec.)
56 mm (2.2 inches)
32767 dots = 409.5 cm (161.25 inches)
25 to 60 mm (1 to 2.36 inches)
40 to 60 mm (1.57 to 2.36 inches)
213 mm (8.38 inches)
38 to 40 mm (1.5 inches) or 76 mm (3 inches)
25 to 60 mm (1 to 2.36 inches)
62 mm (2.44 inches)
25.4 mm (1.00 inches)
4
Yes
Optional
Intermec IPL-3
3 scaleable + 21 simulated bitmap fonts
25
194 x 397 x 178 mm (7.64 x 15.63 x 7.00 inches)
≈ 5.5 kg (12 pounds)
+5°C to +40°C (+41°F to +104°F)
20 to 80% non-condensing
32 bit RISC
2 sockets for 2MB or 4MB each
1
>90 to <264 VAC, 45 to 65 Hz
IEC 61000-3-2
Continuous 140W; Peek 300W
= 448 dots
1
Standard edge guide
Quick-Load guides
Short door/no takeup
≈ 200 m (655 ft) ribbon
With liner takeup unit
With long side door
Std. 1 x 2MB
Std. 4MB
Intermec EasyCoder F2 – User's Guide
