Appendix 1 Technical Data - Intermec EasyCoder F4 Installation & Operation Manual

Technical Data
Printing
Print Technique
Printhead Resolution
Print Speed (variable)
Print Width (max)
Print Length (max)
Media Width (min/max)
Media Width (min/max)
Media Roll Diameter (max)
Media Roll Core Diameter
Ribbon Width (max)
Ribbon Roll Diameter (outer)
Ribbon Roll Core Diameter (inner)
Print Directions
Modes of Operation
Tear-Off (Straight-through)
Peel-Off (Self-strip)
Firmware
Operating System
Smooth Fonts
Built-in scalable fonts (std)
Built-in bar code symbologies (std)
Startup Program (std)
Physical Measures
Dimensions (W x L x H)
Weight (excluding media)
Ambient Operating Temperature
Humidity
Electronics
Microprocessor
On-board Flash SIMMs
On-board DRAM SIMM
Real-Time Clock
Power Supply
Mains Voltage
PFC Regulation
Maximum Power Consumption
Intermec EasyCoder F4 – Installation & Operation Ed. 3
Thermal Transfer and/or Direct Thermal
8 dots/mm (203.2 dpi)
100 to 200 mm/sec. ( 4 to 8 inches/sec.)
104 mm (4.095 inches)
32767 dots = 409.5 cm(161.25 inches)
25 to 114.3 mm (1 to 4.5 inches)
40/80 to 114.3 mm (1.57/3.15 to 4.5 inches)
213 mm (8.38 inches)
38 to 40 mm (1.5 inches) or 76 mm (3 inches)
110 mm (4.33 inches)
62 mm (2.44 inches)
25.4 mm (1.00 inches)
4
Yes
Optional
Intermec Fingerprint v7.40
TrueDoc and TrueType fonts
15
36
Intermec Shell v4.4
244 x 397 x 178 mm (9.61 x 15.63 x 7.00 inches)
7 kg (15.5 pounds)
+5°C to +40°C (+41°F to +104°F)
20 –80% non-condensing
32 bit RISC
1 – 2 x 2 or 4 MB
1
Option
>90 to <264 VAC, 45 to 65 Hz
IEC 61000-3-2
Continuous 140W; Peek 300W
Appendix 1
= 832 dots
1
Standard edge guide
Quick-Load guides
200 m (655 ft) ribbon
with liner takeup unit
Incl. Direct Protocol
Unicode fonts
with long side door
Depending on model
Std. 1 x 2 MB
Std. 4 MB
10+ years life
2
95
