Appendix 1
Technical Data
Printing
Print Technique
Printhead Resolution
Print Speed (variable)
Print Width (max)
Media Width (min/max)
Print Length (max)
Media Roll Diameter (max)
Media Roll Core Diameter
Ribbon Width
Ribbon Length (max)
Print Directions
Modes of Operation
Tear-Off (Straight-through)
Peel-Off (Self-strip)
Internal Batch Takeup
Cut-Off
Firmware
Operating System
Smooth Fonts
Built-in scalable fonts (std)
Built-in bar code symbologies (std)
Startup Program (std)
Physical Measures
Dimensions (W x L x H)
Weight (excluding media and options)
Ambient Operating Temperature
Humidity
Electronics
Microprocessor
On-board Flash SIMMs
On-board DRAM SIMM
Real-Time Clock
Power Supply
AC Voltage
PFC Regulation
Maximum Power Consumption
90
Thermal Transfer and Direct Thermal
12 dots/mm (304.8 dpi)
100 to 300 mm/sec. ( 4 to 12 inches/sec.)
106.6 mm (4.20 inches)
25 to 120 mm (1 to 4.72 inches)
32767 dots = 2,730 mm(107.5 inches)
205 mm (8 inches)
38 to 40 mm (1.5 inches) or 76 mm (3 inches)
25 to 110 mm (1 to 4.33 inches)
450 metres (1,475 ft)
4
Yes
Optional
Optional
Optional
Intermec Fingerprint v7.61
TrueDoc and TrueType fonts
15
38
Intermec Shell v4.8
275 x 480 x 238 mm (10.8 x 18.9 x 9.4 inches)
13 kg (28.7 pounds)
+5°C to +40°C (+41°F to +104°F)
20 to 80% non-condensing
32 bit RISC
3 sockets for 2 or 4MB each
2 sockets for 4 – 32 MB
Yes
>90 to <264 VAC, 45 to 65 Hz
IEC 61000-3-2
Continuous 175W; Peek 400W
1
Intermec EasyCoder 501 XP – User's Guide
With liner takeup unit
With liner takeup unit
With paper cutter
Incl. Direct Protocol
2
Unicode fonts
Std. 1 x 2MB
Std. 1 x 4MB
10+ years life
