Technical Data (Standard model)
Print Technique
Print Resolution
Quick-mount Printhead
Maximum Print Width
Maximum Media Width
Smooth Fonts
Print Directions
Maximum Internal Media Roll Diameter
Maximum Ribbon Length
Dimensions (W x D x H)
Weight (excluding media, ribbon, & options) 4.7 kgs (10.3 pounds)
Ambient Operating Temperature
Humidity
Sound Emission Level
Microprocessor
Firmware
Label and Ribbon End Sensors
AC Input Voltage
PFC Regulation
Maximum Power Consumption
Communications Interface Standard
Print Speed (tear-off/cut-off)
Print Speed (peel-off/roll Ø 152 mm)
Print Speed (LTS enabled)
Bar Code Generators
On-board Flash EPROMs
On-Board RAM Memory
RS-232 Cable
Centronics Parallel Cable
Real Time Clock (RTC)
Label Taken Sensor
Scaleable Fonts
Memory Card Slot
Paper Cutter
Intermec EasyCoder E4 – User's Guide
Direct Thermal/Thermal Transfer
8 dots/mm (203.2 dots/inch)
Yes
104 mm (4.09 inches)
114 mm (4.5 inches)
Yes
4
152 mm (6 inches)
~200 metres (656 feet)
236 x 350 x 170 mm (9.3 x 13.78 x 6.7 inches)
+5°C to +40°C (+41°F to +104°F)
20 to 80% non-condensing
< 60 dB (A)
32 bit
Intermec EasyCoder E4 Direct Protocol v2.10
Yes
110 to 120/220 to 240 VAC, 4/2A, 60/50Hz
IEC 61000-3-2
Stand-by 30W; Typical label 70W; Maximum 250W
1 x RS-232 Serial and 1 x Centronics Parallel
100 or 150 mm/sec (4 or 6 inches/sec)
100 mm/sec. (4 inches/sec)
100 mm/sec. (4 inches/sec)
38
2 x 512K
512K
Optional
Standard
Optional
Fitted
Built-in
1 PCMCIA 5V Type 3, or 2 PCMCIA 5V Type 1 or 2
Optional
Appendix 1
Build option
Rec.
47
