12
MENU SCREEN OPERATION

■ DUP/TONE set mode items

D Offset frequency
Sets the offset frequency for duplex
within a 0 to 159.995 MHz range.
OFFSET FREQ OFFSET FREQ
0.000.00 0.000.00
The default value may differ according to the selected fre-
quency band
(before accessing DUP/TONE set mode)
ceiver version.
The selected tuning step in VFO mode is used when set-
ting the offset frequency.

D Repeater tone frequency

Selects subaudible tone frequency for accessing a repeater,
etc. 50 tone frequencies
REPEATER TONE REPEATER TONE
88.5 88.5
110
operation
(repeater)
OFFSET FREQ OFFSET FREQ
159.995.00 159.995.00
and trans-
are available.
(67.0–254.1 Hz)
(default: 88.5)
REPEATER TONE REPEATER TONE
254.1 254.1
D TSQL frequency
Selects tone frequency for tone squelch or pocket beep op-
eration from one of 50 available frequencies
CTCSS TONE CTCSS TONE
88.5 88.5
• Available subaudible tone frequencies
67.0 79.7 94.8 110.9 131.8
69.3 82.5 97.4 114.8 136.5
71.9 85.4 100.0 118.8 141.3
74.4 88.5 103.5 123.0 146.2
77.0 91.5 107.2 127.3 151.4
The transceiver has 50 tone frequencies and conse-
quently their spacing is narrow compared with units
having 38 tones. Therefore, some tone frequencies may
receive interference from adjacent tone frequencies.
.
(67.0–254.1 Hz)
(default: 88.5)
CTCSS TONE CTCSS TONE
254.1 254.1
156.7 171.3 186.2 203.5 229.1
159.8 173.8 189.9 206.5 233.6
162.2 177.3 192.8 210.7 241.8
165.5 179.9 196.6 218.1 250.3
167.9 183.5 199.5 225.7 254.1
