DV MODE OPERATION

Although [DIAL] and [ ](5) are used for description in this
section, [ ](2)/[ ](8) and [ ](6) are available instead of
[DIAL] and [ ](5).

■ Digital mode operation

The IC-E92D can be operated in digital voice mode and
low-speed data operation for both transmit and receive. It
can also be connected to a GPS receiver
RS-232 output/NMEA format/4800 bps/9600 bps)
ceive position data.

■ Call sign programming

Four types of call sign memories are available; your own
call sign "MY CALL SIGN," other station call sign "YOUR
CALL SIGN," repeater call sign "RPT1 CALL SIGN" and
"RPT2 CALL SIGN." "MY CALL SIGN" can store up to 6 call
signs, "YOUR CALL SIGN" can store up to 60 call signs and
"RPT1/2 CALL SIGN" can store up to 60 call signs, and each
call sign can be programmed with up to 8 characters.
34
D Your own call sign programming
Your own call sign must be programmed for both digital voice
and low-speed data communications
sion)
q Select B band as the main band.
w Enter "MY" in call sign set mode.
❮MENU screen❯
(Push [MENU/
• Pushing and holding [CS](9) for 1 sec. is also available to enter
(compatible with an
call sign set mode.
and transmit/re-
• MY CALL SIGN screen is displayed.
e Rotate [DIAL]
"M01" to "M06."
r Push [ ](6) to enter call sign programming mode.
• The 1st digit blinks.
t Rotate [DIAL]
• Push [A/a](3) to change the character group from "AB" (alpha-
betical characters; capital letters), "12" (numbers) and "/" (sym-
bols) in sequence.
.
➪
❮CALL SIGN❯
]) (Rotate [DIAL]
MY CALL SIGN MY CALL SIGN
r
M01 M01
/ /
:SET :SET
:BACK :BACK
CLR:CLR CLR:CLR
†
to select the desired call sign memory,
MY CALL SIGN MY CALL SIGN
r
M01 M01
†
/ /
:SET :SET CLR:CLR CLR:CLR
:SEL :SEL A/a:CHAR A/a:CHAR
:CUR :CUR
†
to select the desired character or code.
(including GPS transmis-
(p. 14)
➪
❮MY❯
† ‡
, then push [ ](5) .)
:SEL :SEL
:EDIT :EDIT
AB AB
