Icom IC-E92D Instruction Manual page 53

• Setting example 2
Zone A
Area 1
Repeater 1
: A11111
Zone B
Area 5
Repeater 5
: B55555
❑ The setting when Station A is call-
ing Station C
UR : B6666C
R1 : A22222
R2 : A33333 G
MY : A2222A
Area 2
Repeater 2
: A22222
Station A
: A2222A
Area 6
Repeater 6
: B66666
Station C
: B6666C
❑ The setting when Station A is
making a CQ call in Area 8
UR : /B88888
R1 : A22222
R2 : A33333 G
MY : A2222A
DV MODE OPERATION
Repeater 3 3 Repeater 3 Repeater 3
: A33333 : A33333 : A33333
Area 3
(Gateway)
Station B
Internet Internet Internet : A3333B
network network network
Area 7
(Gateway)
Repeater 7
: B77777
❑ The setting when Station B is call-
ing Station C
UR
R1
R2
MY
*Repeater operation is available even if it doesn't input "R2".
7
Area 4
Repeater 4
: A44444
Area 8
Repeater 8
: B88888
: B6666C
: A33333 G
: NOT USE✱*
: A3333B
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
45
