SPECIFICATIONS
D Receiver
• Receive system
Except WFM
WFM
• Intermediate frequencies :
1st A band
B band
2nd
3rd
• Sensitivity
(except spurious points)
AM
(1 kHz/30% Mod.; 10 dB S/N)
0.495–4.995 MHz
5.000–29.995 MHz
118.000–137.000 MHz
222.000–246.995 MHz
247.000–329.995 MHz
FM
(1 kHz/3.5 kHz Dev.; 12 dB SINAD)
VHF (Amateur band only) 0.14 µV typ.
UHF (Amateur band only) 0.16 µV typ.
1.625–29.995 MHz
30.000–117.995 MHz
118.000–173.995 MHz
174.000–259.995 MHz
260.000–349.995 MHz
350.000–469.995 MHz
470.000–599.995 MHz
600.000–999.990 MHz
WFM
(1 kHz/52.5 kHz Dev.; 12 dB SINAD)
76.000–108.000 MHz
175.000–221.995 MHz
470.000–770.000 MHz
DV
(digital/PN9 4.8 kbps; BER 1%)
VHF
(Amateur band only)
UHF
(Amateur band only)
134
:
Double-conversion superheterodyne
Triple-conversion superheterodyne
61.65 MHz/59.25 MHz
(WFM only)
46.35 MHz
450 kHz/13.35 MHz
(WFM only)
1.95 MHz
(WFM only)
:
1.3 µV typ.
0.56 µV typ.
0.5 µV typ.
0.79 µV typ.
1 µV typ.
0.4 µV typ.
0.25 µV typ.
0.14 µV typ.
0.32 µV typ.
0.32 µV typ.
0.16 µV typ.
0.32 µV typ.
0.56 µV typ.
1 µV typ.
1.8 µV typ.
2.5 µV typ.
0.22 µV typ.
0.22 µV typ.
• Audio output power : More than 200 mW at 10% distortion
with an 8 Ω load
(at 7.4 V DC)
• Selectivity :
FM , AM More than 50 dB
(Wide)
FM , DV More than 45 dB
(Narrow)
WFM More than 300 kHz/–3 dB
Less than 700 kHz/–20 dB
• Ext. speaker connector : 3-conductor 3.5(d) mm; (
• Spurious and image rejection ratio :
VHF More than 60 dB
UHF More than 50 dB
(Intermediate freq.; More than 60 dB)
• Squelch Sensitivity
(except spurious points)
AM
(1 kHz/30% Mod.)
0.495–4.995 MHz
5.000–29.995 MHz
118.000–137.000 MHz
222.000–246.995 MHz
247.000–329.995 MHz
FM
(1 kHz/3.5 kHz Dev.)
1.625–29.995 MHz
30.000–75.995 MHz
76.000–117.995 MHz
118.000–173.995 MHz
174.000–259.995 MHz
260.000–349.995 MHz
350.000–469.995 MHz
470.000–599.995 MHz
600.000–999.990 MHz
WFM
(1 kHz/52.5 kHz Dev.)
76.000–108.000 MHz
175.000–221.995 MHz
470.000–770.000 MHz
˝)/8 Ω
1
⁄
8
:
1.3 µV typ.
0.56 µV typ.
0.5 µV typ.
0.79 µV typ.
1 µV typ.
0.4 µV typ.
0.25 µV typ.
0.25 µV typ.
0.14 µV typ.
0.32 µV typ.
0.32 µV typ.
0.16 µV typ.
0.32 µV typ.
0.56 µV typ.
1 µV typ.
1.8 µV typ.
2.5 µV typ.
