The Building Floor submenu contains the following commands:
Up One Floor - If a drawing has more than one floor, and the current floor is not the top floor, this
●
command will make all layers associated with the next higher floor visible and hide all other layers.
Down One Floor - If a drawing has more than one floor, and the current floor is not the lowest floor,
●
this command will show all the layers associated with the next lower floor visible and hide all other
layers.
Goto Floor - This command opens the Goto Floor dialog. You can select a floor and click the OK
●
button, at which point Summit WMScanner changes the 'current floor' to what the user selects as
well as showing the selected floor. For example, you can show floors 1 and 4 while you are on the
4th floor. Then you can hide the 4th floor and view only the 1st floor.
Show Floors - This command prompts you to select a floor from the Select Drawing Floors to Make
●
Visible dialog (). Once you select the floor, Summit WMScanner makes the layers associated with that
floor visible. You can use this dialog to select and display multiple floors at once.
NOTE
Any layers that were currently visible will remain so in the drawing.
