Specifications - 3Com 3C63100-AC-C - PathBuilder S600 Bridge/router Reference Manual

22 C 1: S
HAPTER YSTEM
Specifications
D
ESCRIPTION
Table 4 lists complete specifications for the Pathbuilder S600. these specifications
are subject to change without notice.
Table 4 PathBuilder S600 Specifications
PLATFORM
Configuration
Power Supplies
Power
Input
Consumption
Environmental
Operating Temperature
Storage Temperature
Humidity
Altitude
Regulatory Compliance
Emissions
Safety
Physical Shelf Dimensions
Rack Mount Width
Rack Mount Spacing
Unit Weight (fully loaded)
Shipping Weight
(continued)
6 slots per shelf
2 redundant and load sharing (1 required)
90 to 135 VAC, 50 to 60 Hz
180 to 265 VAC, 50 to 60 Hz
-44 to -52 VDC
175 watts
0 to 45ºC
-40 to 70ºC
95% @ 40ºC (noncondensing)
14,000 ft. or 4,300 meters
FCC Part 15 rules for a Class A computing device
FCC Part 68
EN55022
EN50082-1
CTR 12
CTR 13
Austel TS-001
Austel AS 3260
UL listed (UL 1950 and 1459)
VDE/TUV (EN 60950)
EN41003
CSA 22.2
Austel AS/NZS35-48
8.75" x 17" x 11" (H x W x D)
(22.3 cm x 43.2 cm x 27.9 cm)
19" (42.6 cm) or
23" (58.42 cm) optional
5 RMU
33 lbs (15 kg)
42 lbs (19 kg)
