Table 10 V.35 DCE Cable Pinouts (60-pin Make to 34-pin Female; Part # 3C63914)
Pin # on 60 Pin
Signal Name Conn
Frame GND 46
Circuit GND 45
RTS 35
CTS 42
DSR 43
DCD 44
DTR 34
LL (not used) 33
SD+ 28
SD- 27
RD+ 18
RD- 17
SCTE+ 26
SCTE- 25
SCR+ 22
SCR- 21
SCT+ 20
SCT- 19
Shorting GR 1 48, 49
Shorting GR 2 50, 51,
Shorting GR 3 53, 54, 55, 56
Step 4: Connect I/O Cabling and Wiring
Direction (For
Pin # on V.35 Conn QSIM)
A
B
C In
D Out
E Out
F Out
H In
K In
P In
S In
R Out
T Out
U In
W In
V Out
X Out
Y Out
AA Out
