In general, the maximum total throughput for the QSIM/HSIM/FAM is 31250
packets per second (pps). This is for full duplex traffic. Cases involving small size
frames requires high processing capacity when compared to that of large size
frames. With small size frames, test results show the PPS performance listed in the
following tables. Note that the maximum PPS is 31250.
Table 32 QSIM Performance at Small Frame Sizes
Frame Data Rate
CLK rate Size for port
(MHz) (Byte) (Mbps)
2 64 2
4 64 4
64 4
128 4
256 4
8 64 8
64 8
64 8
64 8
128 8
256 8
Table 33 HSIM Performance at Small Frame Sizes
Frame Data Rate
CLK rate Size for port
(MHz) (Byte) (Mbps)
1 64 1
64 1
64 1
64 1
64 1
128 1
128 1
128 1
2 64 2
64 2
64 2
128 2
128 2
(continued)
, A
ORTS AND PPLICATIONS
Max.Packet
rate for
port number of
(pps) active ports
3906 4
7751 2
1504 4
635 4
830 4
9435 1
1757 2
977 3
937 4
215 4
147 4
max.packet
rate for
port number of
(pps) loops
1938 1
1938 2
1938 3
1938 4
1938 5
985 1
985 3
985 5
3875 1
3875 3
2247 5
1968 3
1348 5
packet rate
for card
(duplex)
(pps)
31248
31004
12032
5080
6640
18870
7028
5862
7496
1720
1176
packet rate
for card
(duplex)
(pps)
3876
7752
11628
15504
19380
1970
5910
9850
7750
23250
22470
11808
13480
