Table 33 HSIM Performance at Small Frame Sizes (continued)
Frame
CLK rate Size
(MHz) (Byte)
4 64
64
64
128
128
128
8 64
64
128
128
Table 34 FAM Performance at Small Frame Sizes
Max. Frames
per second on
Frame Size each port
64 2908
2908
2695
1796
1328
128 1460
1460
1460
To configure the QSIM/HSIM/FAM Local Management Interface (LMI), follow these
steps:
LMI configuration applies only to Frame Relay ports. The LMI Configuration menu
is not available if the QSIM, HSIM, or FAM port is configured as a DXI or
HDLC/SDLC port.
1 From the List Card menu, select the number corresponding to the slot in which the
QSIM, HSIM, or FAM is installed: between 4-6. The QSIM, HSIM, or FAM
Configuration Port/Card Selection menu appears, as shown earlier in Figure 126.
2 Select the number corresponding to the port you want to configure: 1-4 for the
QSIM; 1 for the HSIM; 1-8 for the FAM. The QSIM, HSIM, or FAM Port
Configuration Selection menu appears, as shown earlier in Figure 127.
Configuring the QSIM/HSIM/FAM Modules
max.packet
Data Rate rate for
for port port
(Mbps) (pps)
4 7751
4 1367
4 781
4 3937
4 3937
4 1270
8 9402
8 605
8 7462
8 654
Number of
Active Ports
4
5
6
7
8
4
6
8
packet rate
for card
number of (duplex)
loops (pps)
1 15502
3 8202
5 7810
1 7874
3 23622
5 12700
1 18804
5 6050
1 14924
5 6540
Total Packets
on card
(duplex)
23264
23264
32340
25144
21248
11680
17520
23360
167
