5
Viewing and
Configuring System
Information
C
ONFIGURING
M , P
ODULES
This chapter tells you how to configure the modules, circuits, and related
applications supported by the PathBuilder
(PathBuilder S600) so that the device can pass traffic. It contains the following
sections:
Viewing and Configuring System Information
n
PathBuilder S600 Configuration Overview
n
Configuring the PathBuilder S600 Shelf and the Application Modules
n
Configuring the Shelf
n
Configuring the Management CPU
n
Configuring Virtual Interfaces
n
Configuring Input Shapers
n
Configuring the STX Module
n
Configuring the OC3/STM-1 UNI Module
n
Configuring the DS3 UNI Module
n
Configuring the E3 UNI Module
n
Configuring the DS1 (or E1) UNI with IMA Modules
n
Configuring the Ethernet Module
n
Configuring the CBR DSX (or E1) Modules
n
Configuring the QSIM/HSIM/FAM Modules
n
Configuring Virtual Circuits
n
The System Administration menu, shown in Figure 70, includes options that allow
you to view and configure system information. In addition to using this menu for
initial configuration, as described in Chapter 3, you can:
Specify general system information.
n
Manage the system clock.
n
View system parameters for the RS-232 ports.
n
View the current firmware version.
n
Download new firmware.
n
Update the flash file system.
n
Reset the interface card.
n
View an equipment list.
n
The following subsections describe these System Administration menu options.
P B
ATH UILDER
,
ORTS AND
® S600 WAN Access Switch
S600
A
PPLICATIONS
