To connect the QSIM, attach the appropriate cable to one of the four ports using
the 60-pin amphenol connector, as shown in Figure 19.
Figure 19 QSIM Connection
Table 9, Table 10, Table 11, Table 12, Table 13, Table 14, Table 15, Table 17, and
Table 16 describe the connector pinouts
Step 4: Connect I/O Cabling and Wiring
Slot 6
Slot 5
Slot 4
Slot 3
V.35
EIA530
RS-422
Router
