2 Build a PVC on the far-end PathBuilder S600 from the MCPU to the OC3 UNI (slot
1 to slot 3), setting the following parameters on the Add Virtual Circuit screen:
traffic shaper—Choose any of the available values (for example 17M).
IP address—You must use a different subnet than the one you used for the
near-end PathBuilder S600.
subnet mask—Specify any acceptable address (for example, 255.255.255.0).
VPI/VCI—You must use the same values as you did for the near-end PathBuilder
S600.
3 On the System Administration menu, set the following:
a Set the default gateway on the far-end PathBuilder S600 to the PVC IP address
you set for the near-end PathBuilder S600 in step 1.
b Set the default gateway on the management station to the local host IP address
of the near-end PathBuilder S600.
For details about setting the default gateway, see "Configuring the Default
Gateway" earlier in this chapter.
4 Apply your IP configuration changes.
a From the main menu, select [1] System Administration.
b From the System Administration menu, select [3] Manage IP Network
Configuration.
c From the Manage IP Network Configuration menu, select [1] Local Host IP
Configuration.
d From the Local Host IP Configuration menu, select [3] Apply IP Configuration
Changes.

In-band Management via the Near-end Dual Ethernet Module

To configure in-band management via the near-end PathBuilder S600 Dual
Ethernet module, follow these steps:
If you use this method, you can manage one PathBuilder S600 in a point-to-point
configuration or as many as 256 remote PathBuilder S600s if all the units are
connected to an ATM network service provided by a local or large Telco
organization.
1 Build a PVC on the near-end PathBuilder S600 from the Dual Ethernet Module
(port 1 or 2) to the OC3 UNI (for example, from slot 4 to slot 3), setting the
following parameters on the Add Virtual Circuit screen:
traffic shaper—Choose any of the available values (for example 17M)
VPI/VCI—Enter any values in the accepted range (for example, 10/101).
2 Attach a hub or Ethernet NIC directly to the Dual Ethernet Module port.
3 Build a PVC on the far-end PathBuilder S600 from the MCPU to the OC3 UNI (slot
1 to slot 3), setting the following parameters on the Add Virtual Circuit screen:
traffic shaper—Choose any of the available values (for example 17M)
IP address—Specify any acceptable address (for example, 192.198.65.3).
subnet mask—Specify any acceptable address (for example, 255.255.255.0).
VPI/VCI—You must use the same values as you did for the near-end PathBuilder
S600.
Performing Initial Configuration 71
