3Com 3C63100-AC-C - PathBuilder S600 Bridge/router Reference Manual page 67

Figure 37 Sample PathBuilder S600 IP Host Setup
PathBuilder
S600
192.73.30.99
192.73.30.100
Community
4 Select [4] Previous Menu to return to the Local Host IP Configuration menu.
5 Select [3] Apply IP Configuration Changes to activate the IP address. The following
prompt appears:
This action will terminate all running TELNET/SNMP sessions.
Are you sure you want to apply IP configuration changes (Y/N)[N]?
6 Enter [Y] to apply your changes.
To enter configure the SLIP management port, follow these steps:
1 From the Manage IP Network Configuration menu, select [1] Local Host IP
Configuration to display the Local Host IP Configuration menu, shown earlier in
Figure 35.
When you apply a change to this menu, you might get logged out if you are using
a Telnet session. The default configuration is Baud rate: 9600, Parity; none, Data
Bits:8, StopBits:1.
2 Select [2] SLIP Port IP Configuration to display the SLIP Port IP Configuration menu,
shown in Figure 38.
Figure 38 SLIP Port IP Configuration Menu
3Com
Performing Initial Configuration 67
