Graphical User
Interface Basics
explorer
tree
device icons
job progress

Menu Bar

O
VERVIEW
The EMS GUI provides a simple and intuitive device management
environment. As shown in
users are organized in an explorer tree (Explorer view) in the left-hand
pane of the EMS GUI main window. The Explorer view is the default view
for the EMS GUI. Element properties (Properties view) are displayed in the
right-hand pane of the EMS GUI main window. The Properties view is the
default view for the right-hand pane of the EMS GUI. For more
information on element views, see
and "Left-hand Pane Views"
window is used to monitor the status of each task being performed on a
device through EMS.
Figure 1 Left and Right Panes of the EMS GUI Main Window
Actual screen captures in this guide may differ from those in the EMS GUI
for your installed system.
The system administrator can create different views of managed
devices and assign specific views to individual users.
The menu bar provides access to specific commands and features
available for the EMS GUI. See
Figure 1, all managed devices, event logs, and
"Right-hand Pane
on page 31. See Figure
Figure 2.
Views"on page 32
1. The Job Progress
