Viewing Numeric Values In Alternative Formats - 3Com 3CR15600 - Enterprise Management Suite Getting Started Manual

182 C 10: O
HAPTER PERATIONS
Viewing Numeric
Values in
Alternative Formats
You can display and edit numeric property values in various data formats,
including:
Octet String
■
ASCII characters
■
Integer
■
IP Address
■
Octal
■
Binary
■
To view numeric values in alternative formats:
1 In the explorer tree, select an element that contains a numeric value.
2 In the right-hand pane, right-click a numeric property.
3 Select any one of the individual data formats, or select All Formats to see
all the available formats at the same time.
The Multi Format Dialog dialog box opens. See
Figure 66 Displaying Data Formats for a Numeric Property
4 If the property you have selected is editable, you may edit the property
and click OK.
Figure 66.
