Editing Simple Properties - 3Com 3CR15600 - Enterprise Management Suite Getting Started Manual

Editing Simple Most of the time, properties are organized in a simple list on the
Properties right-hand pane of the EMS GUI.
You can edit any simple MIB object property that has a white
background. Properties with gray backgrounds are informational
(read-only) properties.
Figure 68
Figure 68 Editing Simple Properties
To edit a simple property:
1 In the explorer tree, select an element that contains a simple property.
2 In the right-hand pane, find an editable property on a tab and select the
property name in the Attribute column (a red border surrounds the
selected property).
The EMS Advisor displays property information.
If the EMS Advisor is closed, click the eye icon in the upper right-hand
corner of the EMS GUI to open it.
3 In the field to the right of the property name, double-click the field and
edit according to your customized needs.
Some simple properties allow you to type numeric values or simple text
and others contain a drop-down list of options to choose from.
Using EMS to Edit Network Device Properties
shows the difference between simple properties.
editable property
informational property
