Control Panel

Adjust Printer

Setting Item
Auto Head Adj.
Manual Head Adj
Auto Band Adj.
Manual Band Adj
Adjust Length
Head Inc. Adj.
64 Printer Parts
Standard Adj. Choose Yes to have the printer print and read a test pattern for
the automatic adjustment of Printhead alignment relative to the
printing direction. (→P.554)
Advanced Adj. Choose Yes to have the printer print and read a test pattern
for the automatic adjustment of Printhead alignment relative to
spaces between nozzles and colors and the printing direction.
(→P.554)
Auto Print Choose On to have the printer automatically execute the
Advanced Adj. operations after you replace the Printhead.
(→P.554)
Choose Yes to print a test pattern for adjustment of Printhead
alignment relative to the printing direction. Enter the adjustment
value manually based on the resulting pattern. (→P.556)
Standard Adj. Choose Yes to have the printer print and read a band adjustment
test pattern for automatic adjustment of the feed amount.
(→P.564)
Advanced Adj. Choose this option when using paper other than genuine Canon
paper, or paper for purposes other than checking output.
Choose Yes to have the printer print and read a band adjustment
test pattern for automatic adjustment of the feed amount. Note
that this function takes more time and requires more ink than
Standard Adj.. (→P.564)
Choose Yes to print a test pattern for adjusting the feed amount
based on the paper type.
(→P.566)
A:High ( Adjust Prints a test pattern for particular types of paper to compensate
Length A ) for paper stretching or shrinkage, after which you can enter the
B:Standard/Draft ( amount of adjustment. (→P.569)
Adjust Length B )
Choose Yes to print a test pattern for adjusting the orientation of
the Printhead. (→P.558)
Description, Instructions
