Setting Item
Line & Pen Smoothing
Manager
ThickenFineLines
AdjustFaintLines
ProcessingOp- Warning
tion
On-the-Fly
PageSizeProcess1
PageSizeProcess2
*1: It is not possible to match the colors and image quality produced by the specified printer exactly.

Adjust Printer

Setting Item
Auto Head Adj.
iPF815
•
•
Select On to print fine lines more distinctly.
If fine lines are printed in colors that do not match the colors
of other shapes, selecting Off may help produce the expected
results. However, lines in some colors may appear broken.
Select On to have any GL2-related warnings displayed.
Selecting On will start printing jobs sooner if you are print-
ing only HP RTL print jobs and printing would not start until
later. However, images may be incomplete in some cases, so
be sure to check the printing results.
Normally, the area available for printing excludes a margin
required by the printer, and images are positioned according-
ly. Selecting On in this setting eliminates any misalignment
of the printing position if the image itself includes a border.
Selecting On will determine the paper size based on the im-
age rendering area.
Standard Adj.
Description, Instructions
If you choose Software
Operation is determined by the application. If nothing is
specified by the application, the result is as shown in the
figure.
Note: By default, this is a 72-sided figure
If you choose Smooth
Description, Instructions
Choose Yes to have the printer print and read a test pattern
for the automatic adjustment of Printhead alignment rela-
tive to the printing direction. (See "Automatic Straight-
ening of Lines and Colors (Auto Head Adj.).")
Printer Parts > Control Panel
→P.668
Main Menu Settings
>
