Maintenance Cartridge

Replacing the Shaft Cleaner

Replace the Shaft Cleaner when you replace the Maintenance Cartridge. New Shaft Cleaner is included
with replacement Maintenance Cartridge.
After you execute Repl. maint cart and replace the Maintenance Cartridge, a message will appear on the
Display Screen requesting you to replace the Shaft Cleaner. Select Yes and press the OK button. Next,
go to step 4.
1.
Press the Menu button to display MAIN MENU.
2.
Press ▲ or ▼ to select Maintenance, and then press the ► button.
3.
Press ▲ or ▼ to select Repl. S. Cleaner, and then press the ► button.
4.
Press ▲ or ▼ to select Yes, and then press the OK button.
After the Carriage is moved, the Display Screen indicates Open Upper Cover.
Note
•
If you do not respond within two minutes, shaft cleaner replacement is canceled and the printer goes
online automatically. In this case, repeat the procedure.
5.
Open the Top Cover.
Note
•
Do not open the Printhead Fixer Lever toward the front.
Accidentally opening the Printhead Fixer Lever toward the front will draw out ink, which consumes ink.
600 Maintenance
