Operating Guide | VLT® Midi Drive FC 280
Table 17: Legend to Section D
(continued)
Number Key
20 Auto On
21 Reset
To adjust the display contrast, press [Status] and the [▲]/[▼] keys.
Parameter Settings
5.4.7
Establishing the correct programming for applications often requires setting functions in several related parameters.
Programming data is stored internally in the drive.
For backup, upload data into the LCP memory.
l
To download data to another drive, connect the LCP to that unit and download the stored settings.
l
Restoring factory default settings does not change data stored in the LCP memory.
l
Changing Parameter Settings with GLCP
5.4.8
Introduction
5.4.8.1
Access and change parameter settings from the Quick Menu or from the Main Menu. The Quick Menu only gives access to a limited
number of parameters.

Changing Parameter Settings

5.4.8.2
1.
Press [Quick Menu] or [Main Menu] on the GLCP.
2. Press [▲] [▼] to browse through the parameter groups, press [OK] to select a parameter group.
3. Press [▲] [▼] to browse through the parameters, press [OK] to select a parameter.
4.
Press [▲] [▼] to change the value of a parameter setting.
5.
Press [◄] [►] to shift digit when a decimal parameter is in the editing state.
6. Press [OK] to accept the change.
7.
Press either [Back] twice to enter Status, or press [Main Menu] once to enter the Main Menu.
View Changes
5.4.8.3
Quick Menu Q5 - Changes Made lists all parameters changed from default settings.
The list only shows parameters which have been changed in the current edit setup.
l
Parameters which have been reset to default values are not listed.
l
The message Empty indicates that no parameters have been changed.
l
Backing-up/Downloading Parameters
5.4.9
1. Press [Off] on GLCP or [Off/Reset] on NLCP to stop the motor before uploading or downloading data.
2.
Press [Main Menu] parameter 0-50 LCP Copy and press [OK].
3.
Select [1] All to LCP to upload data to the LCP, or select [2] All from LCP to download data from the LCP.
4. Press [OK]. A progress bar shows the uploading or downloading progress.
5.
Press [Hand On] or [Auto On] to return to normal operation.
48 | Danfoss A/S © 2024.10
Function
Puts the system in remote operational mode.
• Responds to an external start command by control terminals or serial communication.
Resets the drive manually after a fault has been cleared.
NOTICE
Commissioning
AQ381425076031en-000201 / 130R1223
