Operating Guide | VLT® Midi Drive FC 280
Table 64: Mains Supply 3x200–240 V AC
Drive
Enclosure protection rating IP20 (IP21/Type 1
as option)
Output current
Continuous (3x200–240 V) [A]
Intermittent (60 s overload) [A]
Continuous kVA (230 V AC) [kVA]
Maximum input current
Continuous (3x200–240 V) [A]
Intermittent (60 s overload) [A]
More specifications
Maximum cable cross-section (mains, motor,
brake, and load sharing) [mm
Estimated power loss at rated maximum load
(1)
[W]
Weight enclosure protection rating IP20 [kg
(lb)]
Weight enclosure protection rating IP21 [kg
(lb)]
(2)
Efficiency [%]
1) The typical power loss is at nominal load conditions and expected to be within ±15% (tolerance relates to variety in voltage and cable conditions). Values are based on a typical
motor efficiency (IE2/IE3 border line). Motors with lower efficiency add to the power loss in the drive, and motors with high efficiency reduce power loss. Applies to dimensioning of
drive cooling. If the switching frequency is higher than the default setting, the power losses sometimes rise. LCP and typical control card power consumptions are included. Further
options and customer load sometimes add up to 30 W to the losses (though typically only 4 W extra for a fully loaded control card or fieldbus). For power loss data according to EN
50598-2, refer to https://ecosmart.mydrive.danfoss.com/.
2) Measured using 50 m (164 ft) shielded motor cables at rated load and rated frequency. For energy efficiency class, see chapter Ambient Conditions. For part load losses, see
ecosmart.mydrive.danfoss.com/.
Table 65: Mains Supply 1x200–240 V AC
Drive
Typical shaft output [kW]
Typical shaft output [hp]
Enclosure protection rating IP20 (IP21/Type 1 as option)
Output current
Continuous (3x200–240 V) [A]
Intermittent (60 s overload) [A]
Continuous kVA (230 V AC) [kVA]
Maximum input current
Danfoss A/S © 2024.10
(continued)
PK37
K1
2.2
3.5
0.9
1.8
2.9
4 (12)
2
(AWG)]
29.4
2.3 (5.1)
4.0 (8.8)
96.4
PK55 PK75 P1K1
K1 K1 K1
3.2 4.2 6
5.1 6.7 9.6
1.3 1.7 2.4
2.7 3.4 4.7
4.3 5.4 7.5
38.5 51.1 60.7
2.3 (5.1) 2.3 (5.1) 2.3 (5.1)
4.0 (8.8) 4.0 (8.8) 4.0 (8.8)
96.6 96.3 96.6
PK37 PK55 PK75
0.37 0.55 0.75
0.5 0.75 1.0
K1 K1 K1
2.2 3.2 4.2
3.5 5.1 6.7
0.9 1.3 1.7
Specifications
P1K5 P2K2
K1 K2
6.8 9.6
10.9 15.4
2.7 3.8
6.3 8.8
10.1 14.1
76.1 96.1
2.3 (5.1) 2.5 (5.5)
4.0 (8.8) 5.5 (12.1)
96.5 96.7
P1K1 P1K5
1.1 1.5
1.5 2.0
K1 K1
6 6.8
9.6 10.9
2.4 2.7
AQ381425076031en-000201 / 130R1223 |
P3K7
K3
15.2
24.3
6.1
14.3
22.9
147.5
3.6 (7.9)
6.5 (14.3)
96.7
https://
P2K2
2.2
3.0
K2
9.6
15.4
3.8
127
