Operating Guide | VLT® Midi Drive FC 280
USB or fieldbus connection or RS485 interface adaptor for connecting the control card of the drive with the PC.
l
If RS485 is used, the protocol for serial communication needs to be set to [0] FC-MC in parameter 8-30 Protocol (only accessible through
the LCP). When setting up the option for the first time, ensure to have a commissioning report at hand, see further information in VLT®
Motion Control Tool MCT 10 Operating Guide.
Only LCP software version 7.0 or newer is supported.
Commissioning Test
6.9.3
Introduction
6.9.3.1
EN IEC 61508, EN IEC 62061, and EN ISO 13849 require that the final assembler of the machine validates the operation of the safety
function with a commissioning test. The tests for the configured safety functions are described in the commissioning report generated
by the MCT 10 safe plug-in.
The commissioning test must be performed in the following cases:
At initial start-up of the safety option.
l
After any changes related to the safety function (wiring, components, parameter settings, and so on).
l
After any maintenance work related to the safety function.
l
The commissioning test for systems with safety functions is focused on:
Validating the functionality of safety monitoring and stop functions configured in the drive system.
l
Correct selection of the safety option parameter values.
l
Examining the response of specific monitoring functions to the explicit input of values outside tolerance limits.
l
Perform the commissioning test on the basis of the risk analysis. Adhere to all applicable standards and regulations.
Ensure that the following preconditions are met:
The drive is wired properly. For more information about wiring, see the chapter Installation.
l
All safety equipment such as protective monitoring devices, light barriers, or emergency stop switches are connected and ready for
l
operation.
All motor parameters and command parameters are set correctly in the drive.
l
6.9.3.2 Performing the Commissioning Test
1. Use MCT 10 set-up software to generate the commissioning test report.
2.
Follow the test sequence in the report to ensure proper functioning of the safety option.
3.
Document each individual step of the test.
4. Note the checksum of the safety option parameters in the records.
5.
Do not release the system unless it has successfully passed all individual steps of the test.
6.
Restart the drive and check that the motor runs normally.
Commissioning Test Report
6.9.4
After some operations, for example LCP copy of safe parameters, a commissioning test is required. Follow and approve the test sequence
according to the commissioning test report.
96 | Danfoss A/S © 2024.10
NOTICE
Safety Functions
AQ381425076031en-000201 / 130R1223
