Table 65: Mains Supply 1x200–240 V AC
Drive
Continuous (1x200–240 V) [A]
Intermittent (60 s overload) [A]
More specifications
Maximum cable cross-section (mains and motor) [mm
(AWG)]
Estimated power loss at rated maximum load [W]
Weight enclosure protection rating IP20 [kg (lb)]
Weight enclosure protection rating IP21 [kg (lb)]
(2)
Efficiency [%]
1) The typical power loss is at nominal load conditions and expected to be within ±15% (tolerance relates to variety in voltage and cable conditions). Values are based on a typical
motor efficiency (IE2/IE3 border line). Motors with lower efficiency add to the power loss in the drive, and motors with high efficiency reduce power loss. Applies to dimensioning of
drive cooling. If the switching frequency is higher than the default setting, the power losses sometimes rise. LCP and typical control card power consumptions are included. Further
options and customer load sometimes add up to 30 W to the losses (though typically only 4 W extra for a fully loaded control card or fieldbus). For power loss data according to EN
50598-2, refer to https://ecosmart.mydrive.danfoss.com/.
2) Measured using 50 m (164 ft) shielded motor cables at rated load and rated frequency. For energy efficiency class, see chapter Ambient Conditions. For part load losses, see
ecosmart.mydrive.danfoss.com/.

Mains Supply

9.2
Supply terminals
Supply voltage
Supply voltage
Supply frequency
Maximum imbalance temporary between mains phases
True power factor (λ)
Displacement power factor (cos )
Switching on input supply (L1/N, L2/L, L3) (power-ups) ≤7.5 kW (10
hp)
Switching on input supply (L1/N, L2/L, L3) (power-ups) 11–22 kW
(15–30 hp)
1) The drive can run at -25% input voltage with reduced performance. The maximum output power of the drive is 75% if input voltage is -25%, and 85% if input voltage is -15%. Full
torque cannot be expected at mains voltage lower than 10% below the lowest rated supply voltage of the drive.

Motor Output and Motor Data

9.3

Motor Output (U, V, W)

9.3.1
Output voltage
Output frequency
128 | Danfoss A/S © 2024.10
(continued)
PK37
2.9
4.6
2
4 (12)
(1)
37.7
2.3 (5.1)
4.0 (8.8)
94.4
PK55 PK75 P1K1
4.4 5.5 7.7
7.0 8.8 12.3
46.2 56.2 76.8
2.3 (5.1) 2.3 (5.1) 2.3 (5.1)
4.0 (8.8) 4.0 (8.8) 4.0 (8.8)
95.1 95.1 95.3
380–480 V: -15% (-25%)
200–240 V: -15% (-25%)
AQ381425076031en-000201 / 130R1223
Specifications
P1K5 P2K2
10.4 14.4
16.6 23.0
97.5 121.6
2.3 (5.1) 2.5 (5.5)
4.0 (8.8) 5.5 (12.1)
95.0 95.4
https://
(L1/N, L2/L, L3)
(1)
to +10%
(1)
to +10%
50/60 Hz ±5%
3.0% of rated supply voltage
≥0.9 nominal at rated load
Near unity (>0.98)
Maximum 2 times/minute
Maximum 1 time/minute
0–100% of supply voltage
0–500 Hz
