Operating Guide | VLT® Midi Drive FC 280
Table 14: Legend to Section B
Number Key
6 Status
7 Quick Menu
8 Main Menu
9 Alarm Log
C. Navigation keys and indicator lights (LEDs)
Navigation keys are used for programming functions and moving the display cursor. The navigation keys also provide speed control in
local operation. There are also 3 drive status indicator lights in this area.
Table 15: Legend to Section C, Navigation Keys
Number Key
10 Back
11 Cancel
12 Info
13 Navigation keys
14 OK
Table 16: Legend to Section C, Indicator Lights (LEDs)
Number Indicator
15 On
16 Warn
17 Alarm
D. Operation keys and reset
Operation keys are at the bottom of the LCP.
Table 17: Legend to Section D
Number Key
18 Hand On
19 Off
Danfoss A/S © 2024.10
Function
Shows operational information.
Allows access to programming parameters for initial setup instructions and many detailed applica-
tion instructions.
Allows access to all programming parameters.
Shows a list of current warnings, the last 10 alarms, and the maintenance log.
Function
Reverts to the previous step or list in the menu structure.
Cancels the last change or command as long as the display mode has not changed.
Press for a definition of the function being shown.
To move between items in the menu, use the 4 navigation keys.
Press to access parameter groups or to enable a selection.
Light Function
Green ON turns on when the drive receives power from the mains voltage, a DC bus ter-
minal or a 24 V DC external supply.
Yellow When warning conditions are met, the yellow WARN LED turns on, and text ap-
pears in the display area identifying the problem.
Red A fault condition causes the red alarm LED to flash, and an alarm text is shown.
Function
Starts the drive in hand-on mode.
• An external stop signal by control input or serial communication overrides the local hand on.
Stops the motor but does not remove power to the drive.
Commissioning
