Table 69: Enclosure Sizes, Power Ratings, and Dimensions
Enclos K1
ure
size
Weight
IP20 2.5 (5.5)
[kg
(lb)]
IP21 4.0 (8.8)
Mount- a 198 (7.8)
ing
holes
b 60 (2.4)
[mm
(in)]
c 5 (0.2)
d 9 (0.35)
e 4.5 (0.18)
f 7.3 (0.29)
B
Figure 53: Standard with Decoupling Plate
Danfoss A/S © 2024.10
(continued)
K2
3.6 (7.9)
5.5 (12.1)
260 (10.2)
70 (2.8)
6.4 (0.25)
11 (0.43)
5.5 (0.22)
8.1 (0.32)
K3 K4
4.6 8.2 (18.1)
(10.1)
6.5 10.5 (23.1)
(14.3)
260 297.5 (11.7)
(10.2)
90 105 (4.1)
(3.5)
6.5 8 (0.32)
(0.26)
11 12.4 (0.49)
(0.43)
5.5 6.8 (0.27)
(0.22)
9.2 11 (0.43)
(0.36)
C
AQ381425076031en-000201 / 130R1223 |
Specifications
K5
11.5 (25.4)
14.0 (30.9)
390 (15.4)
120 (4.7)
7.8 (0.31)
12.6 (0.5)
7 (0.28)
11.2 (0.44)
