Operating Guide | VLT® Midi Drive FC 280
1
Status
799 RPM 7.83 A
0.000
2
A
53.2 %
4
Auto Remote Ramping
6
Quick
Status
B
Menu
7
10 C
On
OK
15
Warn.
16
Alarm
17
Hand
D
Off
On
18 19
Figure 29: Graphic Local Control Panel (GLCP)
A. Display area
The display area is activated when the drive receives power from the mains voltage, a DC bus terminal or a 24 V DC external supply.
The information shown on the LCP can be customized for user applications. Select options in the Quick Menu Q3-13 Display Settings.
Table 13: Legend to Section A
Display
1
2
3
4
5
B. Display menu keys
Menu keys are used for menu access for parameter setup, toggling through status display modes during normal operation, and viewing
fault log data.
46 | Danfoss A/S © 2024.10
3
1(1)
36.4 kW
5
9
Main Alarm
Menu Log
8
11
12
13
Auto
Reset
On
14
20 21
Parameter number
0-20
0-21
0-22
0-23
0-24
Commissioning
Default setting
[1602] Reference [%]
[1614] Motor Current
[1610] Power [kW]
[1613] Frequency
[1502] kWh Counter
