Operating Guide | VLT® Midi Drive FC 280

The project view shows the F-PLC and the Danfoss device.
4. In the Password for Safety Program dialog box, enter the appropriate password.
5.
Assign the name to the Danfoss device. The name must be the same as shown in parameter 12-08 Host Name.
6.
Select the following I/O protocol: PROFIsafe 30-6/6 Bytes, Standard Telegram 30.
7.
Edit the required PROFIsafe settings under the Properties tab.
The following parameters can be changed, but normally it is only necessary to change the F_Dest_Add parameter:
F_Source_Add - the PROFIsafe address of the PROFIsafe master.
¢
Danfoss A/S © 2024.10
Safety Functions
AQ381425076031en-000201 / 130R1223 | 93
