Commissioning
Indicator Light Function
15 On Green The ON light activates when the
adjustable frequency drive receives
power from the AC line voltage, a
DC bus terminal, or an external
24 V supply.
16 Warn. Yellow When warning conditions are met,
the yellow WARN light comes on
and text appears in the display
area identifying the problem.
17 Alarm Red A fault condition causes the red
alarm light to flash and an alarm
text is displayed.
Table 5.4 Legend to Figure 5.1, Indicator Lights (LEDs)
D. Operation keys and reset
Operation keys are located at the bottom of the LCP.
Key Function
18 Hand On Starts the adjustable frequency drive in local
control.
•
An external stop signal by control input
or serial communication overrides the
local hand on.
19 Off Stops the motor but does not remove
power to the adjustable frequency drive.
20 Auto On Puts the system in remote operational
mode.
•
Responds to an external start command
by control terminals or serial communi-
cation.
21 Reset Resets the adjustable frequency drive
manually after a fault has been cleared.
Table 5.5 Legend to Figure 5.1, Operation Keys and Reset
NOTICE!
The display contrast can be adjusted by pressing [Status]
▲ ▼
and the [ ]/[ ] keys.
MG33AP22
Instruction Manual

5.3.3 Parameter Settings

Establishing the correct programming for applications
often requires setting functions in several related
parameters. Details for parameters are provided in
chapter 9.2 Parameter Menu Structure.
Programming data is stored internally in the adjustable
frequency drive.
•
•
•
5.3.4 Uploading/Downloading Data to/from
the LCP
1.
2.
3.
4.
5.

5.3.5 Changing Parameter Settings

Parameter settings can be accessed and changed from the
Quick Menu or from the Main Menu. The Quick Menu only
gives access to a limited number of parameters.
1.
2.
3.
4.
5.
Danfoss A/S © Rev. 09/2014 All rights reserved.
For backup, upload data into the LCP memory.
To download data to another adjustable
frequency drive, connect the LCP to that unit and
download the stored settings.
Restoring factory default settings does not
change data stored in the LCP memory.
Press [Off] to stop the motor before uploading or
downloading data.
Press [Main Menu] 0-50 LCP Copy and press [OK].
Select [1] All to LCP to upload data to the LCP or
select [2] All from LCP to download data from the
LCP.
Press [OK]. A progress bar shows the uploading
or downloading progress.
Press [Hand On] or [Auto On] to return to normal
operation.
Press [Quick Menu] or [Main Menu] on the LCP.
▲ ▼
Press [ ] [ ] to browse through the parameter
groups, press [OK] to select a parameter group.
▲ ▼
Press [ ] [ ] to browse through the parameters,
press [OK] to select a parameter.
▲ ▼
Press [ ] [ ] to change the value of a parameter
setting.
Press [◄] [►] to shift digit when a decimal
parameter is in the editing state.
5 5
