Operating Guide | VLT® Midi Drive FC 280
Status Bits for Safety Option Status 2
6.7.1.4.3
Parameter 42-81 Safe Option Status 2 indicates which digital input of the safety option is activated in pending state or in blank initial
state.
Table 39: Status Bits for Safety Option Status 2
Bit Description
0 DI safety status
1
2–3 Reserved
4 Blank initial state
5 Safe fieldbus support
6
7
8 Safe function status on safe fieldbus
9 Safe fieldbus communication established
10–31 Reserved
Copying Safe Parameter Setup
6.7.1.5
To copy the safe parameter setup to another drive, see the following steps:
1. Prepare a commissioning report.
2.
Select [1] All to LCP in parameter 0-50 LCP Copy. Monitor the upload on the progress bar.
3.
Install the LCP with all the copied parameters on the drive that must be updated.
4. Select [2] All from LCP in parameter 0-50 LCP Copy. The normal password protection can be applied in parameter 0-60 Main
Menu Password.
5. Enter the password for copied SO configuration (= safe parameters) from LCP.
6. Accept the download of the safe parameters to the drive, which now has a new configuration assigned to it.
7.
Reset the drive to activate the new configuration.
Password Protection LCP Copy and Safe Parameter Mismatch
6.7.1.6
Optionally, a password protection can be used for the function LCP copy (see
41). Password protection can be enabled/disabled in parameter 0-69 Password Protection of Safety Parameters. The password is set in
parameter 0-68 Safety Parameters Password. Default password is 300.
Danfoss A/S © 2024.10
State
00: inactive
01: active
10: pending
11: error
–
0: inactive
1: active
0: no safe fieldbus supported
1: PROFIsafe supported
2: FSoE supported
3: CIP Safey supported
4: openSAFETY supported
0: deactivated
1: activated, safe fieldbus communication is established.
0: not established
1: established
–
40) and if there is a parameter mismatch (see
Table
AQ381425076031en-000201 / 130R1223 |
Safety Functions
Table
