Table 49: Status Word 2
Bit Name
0–1 DI safety status
2–3 Reserved
4 Blank initial state
5–7 Safe fieldbus support
8 Safe function status on safe fieldbus
9 Safe fieldbus communication established
10–31 Reserved
Declarations and Certifications
6.13
According to the requirements set out in the PI document PROFIsafe - Test Specification Order No.: 2.242, chapter 6 Manufacturer
obligations, the PROFIsafe device is designed and has been verified also to fulfill the following properties:
Each time the CRC2 calculation results in 0, the result is set to 1. This rule is described in IEC 61784-3-3 ed.3, chapter 3.3 Conventions.
l
The PROFIsafe watchdog is only retriggered when changing the (virtual) consecutive number. This rule is described in IEC 61784-3-3
l
ed.3, Table 11: statements restart device-timer.
Transfer failsafe values at the first 3 PROFIsafe telegram cycles to the PROFIsafe Device physical output signal independently of the
l
user data from the F-Host. This rule is described in IEC 61784-3-3 ed.3, Table 10: Transition T27: statement if ok_nr_cycles <4, then
use FVo, FV_activated =1.
The reception of zero-telegrams is ignored. If a zero-telegram (all values are 0) is received, the PROFIsafe watchdog continues to run
l
to make sure possible timeouts can be recognized. This rule is described in IEC 61784-3-3 ed.3, Table 10: statement ignore safety
PDU with all values = 0.
The PROFIsafe implementation has been verified by code inspections and module tests for these properties. The verifications and
inspections have shown the functional correctness.
Danfoss A/S © 2024.10
Description
00: Inactive
01: Active
10: Pending
11: Error
–
0: Inactive
1: Active
0: No safe fieldbus supported.
1: PROFIsafe supported.
2: FSoE supported.
3: CIP safety supported.
4: openSAFETY supported.
0: Deactivated.
1: Activated, safe fieldbus communication is established.
0: Not established.
1: Established.
–
