Table 47: Safety Related Parameters
Parameter Option/range
0-0xFFFFFFFF
Parameter 42-83
Safe Status Word
Parameter 42-85 [0] STO
Active Safe Func.
[9] SS1-t
[10] None
–
Parameter 42-86
Safe Option Info
0.00–99.99
Parameter 42-88
Supported
Customization File
Version
0.00–99.99
Parameter 42-89
Customization File
Version
0–65535
Parameter 600-44
Fault Message
Counter
0–65535
Parameter 600-47
Fault Number
0–65535
Parameter 600-52
Fault Situation
Counter
Table 48: Status Word 1
Bit Name
0 Normal up
1 PUST
Danfoss A/S © 2024.10
(continued)
Default
0
[10] None
0
2.00
2.00
0
0
0
Description
0: Safety function, fail-safe reaction is active or pending or warning is active.
1: Normal operation.
0: SFBC is not in the PUST state.
1: SFBC in PUST state.
Usage
Shows the safe status word as a hexadeci-
mal value.
Shows the currently active safety function.
Use parameter 0-20 Display Line 1.1 Small
to parameter 0-22 Display Line 1.3 Small
to show the function on the LCP.
Shows the information about the safety
option. Use parameter 0-23 Display Line
2 Large and parameter 0-24 Display Line
3 Large to show the function on the LCP
large display line.
Shows the maximum supported configu-
ration file version.
0.00 means the maximum version sup-
ported by the safe system (the drive with
the safety option).
1.00 means the maximum version sup-
ported by the safety option.
2.00 means the maximum version sup-
ported by the control card.
Shows the currently used customization
file version.
Is incremented each time that the fault
buffer changes.
Contains the internal fault number for
each fault message.
Sum of all of the fault situations since the
last reset.
Safety Functions
Conversion Data type
index
– u_int32
– u_int8
0 Visible
String
-2 u_int16
-2 u_int16
– u_int16
– u_int16
– u_int16
