Table 47: Safety Related Parameters
Parameter Option/range
–
Parameter 42-33
Parameter Set
Name
–
Parameter 42-35 S-
CRC Value
–
Parameter 42-36
Level 1 Password
0.1–3600.0 s
Parameter 42-42
Delay Time
0-99%
Parameter 42-43
Delta T
Parameter 42-60 [0] None
Telegram Selection
[1] PROFIsafe Std.
Tel. 30
1–65534
Parameter 42-61
Destination
Address
0-0xFFFFFFFF
Parameter 42-80
Safe Option Status
0-0x7FFFFFFF
Parameter 42-81
Safe Option Status
2
0-0xFFFFFFFF
Parameter 42-82
Safe Control Word
104 | Danfoss A/S © 2024.10
(continued)
Default
SafeSet1
–
12345678
10.0 s
2%
[0] None
1
0
0
0
Usage
Enter the name of the safety parameter
set (8 characters). Use this parameter to
identify the safety configurations.
The CRC value of safe parameter set.
Password for safe parameter set to pre-
vent unauthorized modification.
Time until STO is activated.
The value subtracts from the time in
parameter 42-42 Delay Time to get the
motor to stop before the timer expires.
Select the safe fieldbus type and the
telegram standard for the safety option.
Selecting [0] None means the safe fieldbus
communication is disabled.
Selecting [1] PROFIsafe Std. Tel. 30 means
that the PROFIsafe communication is
enabled, and the telegram standard is
PROFIsafe Std. Tel. 30. PROFIsafe Std.
Tel. 30. For more information, see
PROFIsafe.
If the fieldbus communication is enabled
and the reset signal comes via the field-
bus, this parameter also defines whether
the drive is reset or only the safety option
is reset.
Enter the safe fieldbus destination address
within the safe network. This address
must be unique in the network where
PROFIsafe operates. The address should
match the address specified in the PLC
software.
Shows the status word 1 of the safety op-
tion as a hexadecimal value. Refer to
48.
Shows the status 2 word of the safety op-
tion as a hexadecimal value. Refer to
49.
Shows the safe control word as a hexadec-
imal value.
Safety Functions
Conversion Data type
index
– Visible
String
– u_int16
– Visible
String
-1 u_int16
0 u_int8
– u_int8
6.5.1
– u_int16
0 u_int32
Table
0 u_int32
Table
– u_int32
