Operating Guide | VLT® Midi Drive FC 280
Table 10: Changing Values in Continuous Parameters
7 [▼]: Decreases the parameter value, the decimal point changes automatically.
8 [▲]: Increases the parameter value.
9 [Back]: Cancel changes, return to 2.
[OK]: Accept changes, return to 2.
10 [▲][▼]: Select parameter within the group.
11 [Back]: Removes the value and shows the parameter group.
12 [▲][▼]: Select group.
5.4.5.3 Enumerated Parameters
For enumerated parameters, the interaction is similar, but the parameter value is shown in brackets because of the digits limitation (4
large digits) on the NLCP, and the enum can be greater than 99. When the enum value is greater than 99, the LCP can only show the 1st
part of the bracket.
Setup 1
1
OK
Setup 1
2
OK
Setup 1
Figure 27: Main Menu Interactions - Enumerated Parameters
Table 11: Changing Values in Enumerated Parameters
1 [OK]: The 1st parameter in the group is shown.
2 Press [OK] to start editing.
3 [▲][▼]: Change parameter value (flashing).
4 Press [Back] to cancel changes or [OK] to accept changes (return to screen 2).
5 [▲][▼]: Select a parameter within the group.
6 [Back]: Removes the value and shows the parameter group.
7 [▲][▼]: Select a group.
44 | Danfoss A/S © 2024.10
(continued)
7
6
5
4
OK
3
Commissioning
