9

Parameter descriptions

It is intended that it is not necessary to use option module parameters for EtherCAT setup or control
of a drive; parameters are mostly provided for status and information. This means that a user will
configure the motor and feedback in the usual way, using parameters, install an EtherCAT option,
and use CoE; objects to control the drive from that point onwards. Although, with objects which
correspond to drive parameters, it should be possible to perform all drive/motor/feedback
configuration using the EtherCAT interface.
In the following descriptions, S means the option module slot number.
9.1

Internal menus

SI-EtherCAT provides parameters for configuration and information, these parameters are grouped
into menus as shown in Table 9-1.
Table 9-1 SI-EtherCAT internal menus
Menu Name
S.00 Setup
S.01 ECAT Status
S.02 EoE Status
S.03 Motion Profile
S.09 Resources
9.2

Parameter type codes

Table 9-2 lists the coding used for the parameter type in the subsequent parameter description
tables.
Table 9-2 Parameter type codes
RW Read / Write RO
Character
Chr Bin
parameter
Number
Num DE
parameter
FI Filtered US
SI-EtherCAT User Guide
Provides module information such as firmware version and serial number
Provides information on the EtherCAT network status
Provides information on the Ethernet over EtherCAT status and configuration
Provides information on CiA402 Motion profile
Provides information on the module task resources and PCB temperature
Bit
Read-only Bit
parameter
Binary
IP IP address
parameter
No default
Destination ND
value
Power-down
User save PS
save
Description
Txt Text string Date
Mac MAC address Ver
Rating
RA NC
dependant
Bit default or
BU
unipolar
Date Time
Time
parameter parameter
Version Slot, menu,
SMP
number parameter
Non-
PT Protected
copyable
127
