10.7

Updating SI-EtherCAT firmware

The latest SI-EtherCAT firmware is available from your local Control Techniques Drive Centre or
supplier. To upload firmware to SI-EtherCAT a copy of Unidrive M Connect and a suitable
communications lead for the option module's host drive is required.
10.8

Sync Task Orun trips

If SI-EtherCAT cannot complete the assigned tasks within its 250 µs Synchronous Task, a Sync
Task Orun trip will be initiated; a Sync Task Orun trip indicates that the user is trying to accomplish
too much within the Synchronous task. The user can influence the Synchronous Task by reducing
the amount of cyclic data, or disabling drive control CiA402. To disable drive control set the
Pr S.00.033 to On (1).
10.9

EtherCAT AL status codes

Table 10-15 shows the possible AL (Application Layer) status codes returned to the EtherCAT
master controller during configuration or operational mode.
Table 10-15 Application Layer status codes
Code
Meaning
(0x)
0000 No error
0001 Unspecified error
0002 No memory
Invalid requested state
0011
changed
Unknown requested state
0012
change
0013 Boot state not supported
0014 No valid firmware
0015 Invalid mailbox configuration
0016 Invalid mailbox configuration
Invalid Sync Manager
0017
configuration
0018 No valid inputs available
0019 No valid outputs available
001A Synchronization error
001B Sync Manager watchdog
001C Invalid Sync Manager Types
001D Invalid output configuration
160
Description
No error
No error code has been defined
Insufficient memory for operation
Requested state change is invalid
Requested state change is
unknown
Device does not support BOOT
state
Downloaded firmware application
file is invalid
Mailbox configuration differs from
expected settings
Slave device changed but network
configuration is unchanged
PDO length, address or direction
mismatch
No valid inputs available on Slave
device
Slave device cannot receive valid
output values
Too many RxPDO toggle errors
have occurred
No process data received within
specified timeout
Specified Sync Manager type is
invalid
Sync Manager for output process
data is invalid
Comment
Contact supplier
Contact supplier
Follow the EtherCAT State
Machine sequence to change
state
Use only the EtherCAT State
Machine state values
Contact supplier
Download correct firmware
application file
Replace network description
file with the correct file for
device
Replace previous network
description of old slave with the
one of the new slave.
Issue a re-calculation of the
EtherCAT configuration.
Check slave input objects
Check slave output objects
Check configuration
Check process data
configuration
Use correct Sync Manager
Use correct Sync Manager
