7.4.2 0x60C1 Interpolation_data_record
This object is used to specify the target position. Linear interpolation is used to generate position
demand values every 250 µs. The position is specified in user-defined position units. The value is
written into sub-index 1.
Table 7-51 0x60C1 Interpolation_data_record
0x60C1 Interpolation_data_record
Sub-index 0
Access: RO
Default: 1
PDO Mappable: No
Motion Profiles: IP
Description: This object is used to specify the target position.
Sub-index 1
Access: RW
Default: N/A
PDO Mappable: RxPDO
Description: The set-point.
7.4.3 0x60C2 Interpolation_time_period
Table 7-52 Interpolation_time_period
0x60C2 Interpolation_time_period
Sub-index 0
Access: RO
Default: 2
PDO Mappable: No
Motion Profiles: CSP, CSV, CST, IP
Description: The number of the last sub-index in this object.
Sub-index 1
Access: RW
Default: 250
PDO Mappable: No
The number of time units between interpolator restarts. A time unit is defined by sub-index 2.
Description: The interpolator time period value will be checked to ensure that it is valid. Valid values are
250 µs, 500 µs or any multiple of 1 ms. Selecting other values will result in an error indication.
Sub-index 2
Access: RW
Default: -6 (a time unit of 1 µs)
PDO Mappable: No
This specifies the time unit for the interpolation time period. Sub-index 2 specifies the unit
Description:
exponent. The time unit, therefore, is 10
time unit to be 1 µs, and the longest to be 1 s.
