0x1A02 Transmit PDO mapping 3
nd
Sub-index 2: 2 Mapped Object
Access: RW
0x60640020 - the CiA402 actual
Default:
position (0x6064)
PDO Mappable: No
A mapping to an object. This will have the following format:
Bits 0 to 7: Length of the mapped object in bits, e.g. a 32-bit parameter would have a length of
Description: 32 or 0x20.
Bits 8 to 15: Sub-index of the mapped object.
Bits 16 to 31: Index of the mapped object.
Table 6-23 TxPDO mapping 5
0x1A04 Transmit PDO mapping 5
Sub-index 0: Number Of Mapped Objects
Access: RW
Default: 2
PDO Mappable: No
Description: The number of mapped objects in this PDO.
st
Sub-index 1: 1 Mapped Object
Access: RW
0x60410010 - the CiA402 status
Default:
word (0x6041).
PDO Mappable: No
A mapping to an object. This will have the following format:
Bits 0 to 7: Length of the mapped object in bits, e.g. a 32-bit parameter would have a length
Description: of 32 or 0x20.
Bits 8 to 15: Sub-index of the mapped object.
Bits 16 to 31: Index of the mapped object.
Sub-index 2: 2nd mapped object
Access: RW
0x60770010 - the CiA402 actual
Default:
torque (0x6077)
PDO Mappable: No
A mapping to an object. This will have the following format:
Bits 0 to 7: Length of the mapped object in bits, e.g. a 32-bit parameter would have a length
Description: of 32 or 0x20.
Bits 8 to 15: Sub-index of the mapped object.
Bits 16 to 31: Index of the mapped object.
