Control Techniques Nidec SI-EtherCAT User Manual page 40

Table 6-21 TxPDO mapping 2
0x1A01 Transmit PDO mapping 2
Sub-index 0: Number Of Mapped Objects
Access: RW
Default: 2
PDO Mappable: No
Description: The number of mapped objects in this PDO.
st
Sub-index 1: 1 Mapped Object
Access: RW
0x60410010 - the CiA402 status word
Default:
(0x6041)
PDO Mappable: No
A mapping to an object. This will have the following format:
Bits 0 to 7: Length of the mapped object in bits, e.g. a 32-bit parameter would have a length of
Description: 32 or 0x20.
Bits 8 to 15: Sub-index of the mapped object.
Bits 16 to 31: Index of the mapped object.
nd
Sub-index 2: 2 Mapped Object
Access: RW
0x60610008 - the CiA402 modes of
Default:
operation display object (0x6061)
PDO Mappable: No
A mapping to an object. This will have the following format:
Bits 0 to 7: Length of the mapped object in bits, e.g. a 32-bit parameter would have a length of
Description: 32 or 0x20.
Bits 8 to 15: Sub-index of the mapped object.
Bits 16 to 31: Index of the mapped object.
Table 6-22 TxPDO mapping 3
0x1A02 Transmit PDO mapping 3
Sub-index 0: Number Of Mapped Objects
Access: RW
Default: 2
PDO Mappable: No
Description: The number of mapped objects in this PDO.
st
Sub-index 1: 1 Mapped Object
Access: RW
0x60410010 - the CiA402 status word
Default:
(0x6041)
PDO Mappable: No
A mapping to an object. This will have the following format:
Bits 0 to 7: Length of the mapped object in bits, e.g. a 32-bit parameter would have a length of
Description: 32 or 0x20.
Bits 8 to 15: Sub-index of the mapped object.
Bits 16 to 31: Index of the mapped object.
40
Range: 0 to 12
Range: N/A
Range: N/A
Range: 0 to 12
Range: N/A
Size: 1 byte
Type: Unsigned integer / USINT
Update Rate: PreOp -> SafeOp transition
Size: 4 bytes
Type: Bit Mask / UDINT
Update Rate: PreOp -> SafeOp transition
Size: 4 bytes
Type: Bit Mask
Update Rate: PreOp -> SafeOp transition
Size: 1 byte
Type: Unsigned integer / USINT
Update Rate: PreOp -> SafeOp transition
Size: 4 bytes
Type: Bit Mask / UDINT
Update Rate: PreOp -> SafeOp transition
Unit: N/A
Unit: N/A
Unit: N/A
Unit: N/A
Unit: N/A
SI-EtherCAT User Guide
