Control Techniques Nidec SI-EtherCAT User Manual page 150

Table 9-74 Object Index view Selector 1
S.09.050
Minimum
Default
Type
Display Format
Coding
This parameter selects a CAN Object Index to view in Object View Value 1 (S.09.052). The CAN
Object Subindex also need to be configured in Object Subindex View Selector 1(S.09.051).
Setting a value of zero will freeze the value in S.09.052, to that for the previous object selected.
Table 9-75 Object Subindex view Selector 1
S.09.051
Minimum
Default
Type
Display Format
Coding
This parameter selects a CAN Object Subindex to view in Object View Value 1 (S.09.052).
Table 9-76 Object View Value 1
S.09.052
Minimum
Default
Type
Display Format
Coding
This parameter shows the value of object view selector 1.
Table 9-77 Object Index view Selector 2
S.09.053
Minimum
Default
Type
Display Format
Coding
This parameter selects a CAN Object Index to view in Object View Value 2 (S.09.055). The CAN
Object Subindex also need to be configured in Object Subindex View Selector 2 (S.09.054).
Setting a value of zero will freeze the value in S.09.055, to that for the previous object selected.
150
Object Index view Selector 1
0
0
16 bit volatile
Standard
RO, ND, NC, PT
Object Subindex view Selector 1
0
0
8 bit volatile
Standard
RW, NC, PT
Object View Value 1
-2147483648
32 bit volatile
Standard
RO, ND, NC, PT
Object Index view Selector 2
0
0
16 bit volatile
Standard
RW, NC, PT
Maximum
Units
Update Rate
Decimal Places
Maximum
Units
Update Rate
Decimal Places
Maximum
Units
Update Rate
Decimal Places
Maximum
Units
Update Rate
Decimal Places
65535
Written in background
0
255
Written in background
0
2147483647
Written in background
0
65535
Written in background
0
SI-EtherCAT User Guide
