- Page 1 User Guide: Communications module Profinet Profibus Modbus TCP Modbus RTU Ethernet/IP DeviceNet For use with D1/D2 soft starters...
- Page 2 Product Compatibility This communications module is suitable for use with Digistart D1 and D2 soft starters. For the latest manuals and software, please visit our website.
-
Page 3: Table Of Contents
Important User Information ....................2 Warnings ..........................2 Installation ......................... 3 Connection ........................4 Configuration ........................4 DeviceNet Network Settings ..................... 4 Module and Network LEDs ....................5 DeviceNet Polled I/O Structure ..................6 Trip Codes ......................... 7 Specifications ........................8 User Manual... -
Page 4: Disclaimer
Disclaimer DeviceNet Module Disclaimer The examples and diagrams in this manual are included solely for illustrative purposes. The information contained in this manual is subject to change at any time and without prior notice. In no event will responsibility or liability be accepted for direct, indirect or consequential damages resulting from the use or application of this equipment. -
Page 5: Installation
5. Set the DeviceNet Module Node Address (MAC ID) and Data Rate. 6. Apply control power to the soft starter. 7. Insert the network connector into the module and power up the DeviceNet network. CAUTION Network designs must decrease the maximum allowable cumulative dropline length by 400 mm for every device installed on the network. -
Page 6: Connection
The DeviceNet Module is a Group 2 slave device, using a predefined master/slave connection set. I/O data is produced and consumed using polled I/O messaging. The soft starter must be added to the DeviceNet manager project using the EDS file and configuration/management software tool. In order to operate successfully, the correct EDS file must be used. -
Page 7: Module And Network Leds
DeviceNet Module Module and Network LEDs Module and Network LEDs The Module LED indicates the condition of the power supply and device operation. The Network LED indicates status of the communication link between the device and the network Master. LED name LED Status... -
Page 8: Devicenet Polled I/O Structure
DeviceNet Polled I/O Structure DeviceNet Module DeviceNet Polled I/O Structure Once the EDS file has been loaded, the device must be added to the scanner list with parameters shown in the following table: Parameter Value I/O connection type Polled Poll receive size... -
Page 9: Trip Codes
DeviceNet Module Trip Codes Slave > Master polled I/O input data is as follows: Byte Function Value Trip 1 = Tripped Reserved Running 0 = Tripped 1 = Starting, Running or Stopping Reserved Ready 0 = Start or stop command not acceptable... -
Page 10: Specifications
Specifications DeviceNet Module Specifications • Enclosure Dimensions ............40 mm (W) x 166 mm (H) x 90 mm (D) Weight ........................250 g Protection ......................... IP20 • Mounting Spring-action plastic mounting clips (x 2) Connections • Soft starter ..................6-way pin assembly Network ......... - Page 12 7 1 0 - 2 1 3 7 8 - 0 0 A 7 1 0 - 2 1 3 7 7 - 0 0 A 7 1 0 - 2 1 3 7 6 - 0 0 A 7 1 0 - 2 1 3 7 5 - 0 0 A 7 1 0 - 2 1 3 7 4 - 0 0 A 7 1 0 - 2 1 3 7 3 - 0 0 A 7 1 0 - 2 1 3 7 2 - 0 0 A...
