Table 8-5 Product codes in Unidrive SP override
Drive Mode
RFC-A
RFC -S
Open Loop
Regen
Objects Mapped To Parameters That May Not Exist In A Unidrive M
When in Unidrive SP override, the following parameters will be available (via the CoE object
mapping mechanism) that may or may not exist on the drive (depending on the model). If they do
exist, reading and writing work as expected. If they do not exist, a write will succeed, and a read will
return zero.
Table 8-6 Parameters may not exist in Unidrive M
Object / Corresponding
Subindex Unidrive SP parameter
0x2005:17 Pr 5.17
0x2006:22 Pr 6.22
0x2006:23 Pr 6.23
0x2006:24 Pr 6.24
0x2006:25 Pr 6.25
0x2007:19 Pr 7.19
0x2007:20 Pr 7.20
0x2007:21 Pr 7.21
0x2015:12 Pr 21.12
Objects Redirected To Other Parameters
When in Unidrive SP override, the following Unidrive SP parameters will be available (via the CoE
object mapping mechanism) that map to different parameters on the drive. If they do exist, reading
and writing work as expected. If they do not exist, a write will succeed, and a read will return zero.
Table 8-7 Objects redirected to other parameters
Object / Unidrive SP parameter Corresponding
Subindex
0x2006:22 Pr 6.22
0x2006:23 Pr 6.23
0x2006:24 Pr 6.24
0x2006:25 Pr 6.25
Objects That Require Additional Configuration To Work As Expected For Unidrive SP
When in Unidrive SP override, the Run time (years/days/hours/minutes) will only return valid values
if the Unidrive M Date/Time Selector (Pr 06.019 is set to Running (2)).
Objects Values That Are Correctly Scaled To Be Same As Unidrive SP
When in Unidrive SP override, the resolution and size of some on the objects are different to that for
Unidrive M, so a conversion function is invoked when reading and writing to the corresponding
objects.
It must be noted that there may be a loss of accuracy and possible rounding errors. The effected
objects (if the corresponding parameter exists) are as follows:
122
Value
0x30003
0x40003
0x10003
Same as before, no over-ride of product code
Unidrive SP parameter name - for the corresponding menu/
parameter number
Stator Resistance
Run time years and days
Run time hours and minutes
Metered Power MWh
Metered Power kWh
Analogue Output Source
Analogue Output Scaling
Analogue Output Mode
Stator Resistance
Unidrive M parameter
Pr 06.016
Pr 06.017
Pr 06.025
Pr 06.026
Unidrive SP Parameter Name
Run time years and days
Run time hours and minutes
Metered Power MWh
Metered Power kWh
