2-1-2
Checking the Version
The procedure to check the Network Configurator version is as follows:
1.
Select the Control Panel from the Windows Start Menu.
2.
Select the Add or Remove Programs (Windows XP) or Add/Remove Programs (Windows 2000).
3.
Select the Network Configurator for DeviceNet Safety from the installed program list, and then refer
to the support information by following each display.
4.
The version will be displayed as support information.
2-1-3
Main Window
The Main Window consists of the Hardware List, the Network Configuration Pane, and the Message Pane.
Hardware List:
Displays the devices that
can be added to the
network.
Message Report Pane:
Displays information, such as
communications errors.
28
Network Configuration Pane:
Displays the virtual network.
Section 2: Basic Operation of the Network Configurator
