5-5-2
Confirming the Cycle Time
Cycle Time
The NE1A-SCPU01 cycle time is automatically calculated and displayed based on the set parameters and
programs created in the Logic Editor.
The cycle time is used in calculating the reaction time and the ON/OFF delay time settings. Check the value
after all the parameters and programs have been set.
I/O Refresh Cycle
The I/O refresh cycle is used to refresh local I/O. It is automatically calculated with the cycle time and dis-
played.
The I/O refresh cycle time is used in calculating the reaction time.
Check the value after all the parameters and programs have been set.
96
Section 5: Editing Safety Network Controller Parameters
