Page 1 Cat. No. Z906-E1-07 DeviceNet Safety NE1A Series: NE1A-SCPU01(-V1)(-EIP)/ -SCPU02(-EIP) Safety Network Controller OPERATION MANUAL...
Page 5 NE1A Series Safety Network Controller: NE1A-SCPU01(-V1)(-EIP)/-SCPU02(-EIP) Operation Manual Revised July 2009...
Page 7 Indicates general mandatory actions for which there is no specific symbol. OMRON Product References All OMRON products are capitalized in this manual. The word “Unit” is also capitalized when it refers to an OMRON product, regardless of whether or not it appears in the proper name of the product.
Page 8  OMRON, 2005 All rights reserved. No part of this publication may be reproduced, stored in a retrieval system, or transmitted, in any form, or by any means, mechanical, electronic, photocopying, recording, or otherwise, without the prior written permission of OMRON.
Page 9: Table Of Contents
Additional Precautions According to UL 1604 ........
Page 10 SECTION 8 Programming ........133 Outline of Programming .
Page 11 Index..........293 Revision History ........297...
Page 13 Obtain this manual and gain a firm understanding of its contents before using a DeviceNet system.
Page 15 WHETHER SUCH CLAIM IS BASED ON CONTRACT, WARRANTY, NEGLIGENCE, OR STRICT LIABILITY. In no event shall the responsibility of OMRON for any act exceed the individual price of the product on which liability is asserted. IN NO EVENT SHALL OMRON BE RESPONSIBLE FOR WARRANTY, REPAIR, OR OTHER CLAIMS...
Page 16 The following are some examples of applications for which particular attention must be given. This is not intended to be an exhaustive list of all possible uses of the products, nor is it intended to imply that the uses listed may be suitable for the products: •...
Page 17 PERFORMANCE DATA Performance data given in this manual is provided as a guide for the user in determining suitability and does not constitute a warranty. It may represent the result of OMRON's test conditions, and the users must correlate it to actual application requirements.
Page 19 Regulations and Standards ........
Page 20: Intended Audience
!WARNING It is extremely important that a PLC and all PLC Units be used for the speci- fied purpose and under the specified conditions, especially in applications that can directly or indirectly affect human life. You must consult with your OMRON...
Page 21 • Complying with Laws and Regulations This safety device conforms to the relevant regulations and standards, but make sure that it is used in compliance with local regulations and stan- dards for the equipment or facilities in which it is applied.
Page 22: Safety Precautions
Serious injury may possibly occur due to loss of required safety functions. Ground the 0-V line of the power supply for external output devices so that the devices do NOT turn ON when the safety output line or the test output line is grounded.
Page 23: Precautions For Safe Use
NE1A-series Controller) to prevent it falling off the DIN rail because of vibration. • Space must be provided around the NE1A-series Controller, at least 5 mm from its side and at least 50 mm from its top and bottom surfaces, for ventilation and wiring. ■...
Page 24: Additional Precautions According To Ul 1604
• Be cautions not to injure yourself when dismantling the NE1A-series Con- troller. Additional Precautions According to UL 1604 The NE1A-series Controller is suitable for use in Class I, Div. 2, Group A, B, C, D or Non-Hazardous Location Only. WARNING - Explosion Hazard - Substitution of Components May Impair Suit- ability For Class I, Div.
Page 25: Regulations And Standards
NE1A-series Controller unit versions and the revisions. Checking the Unit Version on the Product Nameplate The unit version (Ver. @.@) is listed near the lot number on the nameplate of the products for which unit versions are being managed, as shown below.
Page 26 The unit version is listed here. (Example: Ver. 1.0) Checking the Unit Version with the Network Configurator The following procedure can be used to check the unit version from the Net- work Configurator. 1,2,3... 1. Select Network - Upload to upload the configuration information. The de- vice icons will be displayed, as shown in the following diagram.
Page 27 Unit Versions of NE1A-series Controllers The following Property Dialog Box will be displayed. The device name and revision are given in the Property Dialog Box. The NE1A-series Controllers supported by Network Configurator version 2.2@ are listed in the following table.
Page 28 Checking the Unit Version with the Unit Version Label The following unit version labels are provided with the Controller. These labels can be attached to the front of the Controllers to differentiate between Controller with different unit versions from the front of the Controller.
Page 29 Routing between DeviceNet and EtherNet/IP I/O routing Supported Supported Message routing Supported Supported Note In this manual, any functionality that is supported by unit version 1.0 or later or unit version 2.0 or later is also supported by CPU Units with EtherNet/IP. xxvii...
Page 30 Can be used. sion 2.0 (See note 1.) NE1A-SCPU01-EIP Cannot be used. Cannot be used. Cannot be used. Cannot be used. Can be used. NE1A-SCPU02-EIP Cannot be used. Cannot be used. Cannot be used. Cannot be used. Can be used. Note (1) Can be used as a Controller with unit version 1.0.
Page 31 Functions are added and functionality is expanded in various ways for the NE1A-series Controllers. The device type in an existing network configuration file can be changed to a higher version so that the new functionality can be used. The following table shows the NE1A-series Control device types in network configuration files and the device types that they can be upgraded to.
Page 32 Unit Versions of NE1A-series Controllers Next, select the new device in the New Device and press the OK Button. After a moment, the model number will change and the configuration data for the new device will be completed. 3. Expansion Configuration When the data configuration is converted, all expanded functionality will be set to the default values.
Page 33 Unit Versions of NE1A-series Controllers (2) When changing the device type using Network Configurator version 2.@ or higher, the connection information will be updated automatically. xxxi...
Page 35: Overview Of The Ne1A-Series Safety Network Controllers
1-1-3 Functional Overview........1-1-4 Functions Improved in the Unit Version 2.0 Upgrade .
Page 36: About Ne1A-Series Safety Network Controllers
Introduction to the NE1A-series Safety Network Controllers The NE1A-series Safety Network Controllers provide various functions, such as safety logic operations, safety I/O control, and a DeviceNet Safety protocol. The NE1A-series Controller allows the user to construct a safety control/net- work system that meets the requirements for Safety Integrity Level (SIL) 3...
Page 37: Features Of The Ne1A-Series Controllers
As an EtherNet/IP target, an NE1A-series Controller can perform standard I/O communications with up to two connections with a single EtherNet/IP origina- tor, using up to 128 bytes for input and 16 bytes for output per connection. DeviceNet Communications Disable (Standalone) Setting An NE1A-series Controller can be used as a Standalone Controller by dis- abling its DeviceNet communications.
Page 38: Functional Overview
• The NE1A-series Controller’s internal status information can be moni- tored from a Standard PLC by allocating the information in the Standard Master. In the same way, monitoring with a Safety PLC is possible by allo- cating information in the Safety Master.
Page 39 To protect the circuit, the output is cut off when an overcurrent is tion/protection detected. Dual Channel Mode Both of two paired outputs can be set into a safety state when an error occurs in either of the two paired local outputs without depend- ing on the user program. DeviceNet Communications...
Page 40: Functions Improved In The Unit Version 2.0 Upgrade
Section 1-1 About NE1A-series Safety Network Controllers 1-1-4 Functions Improved in the Unit Version 2.0 Upgrade The following table outlines the changes made in the unit version 2.0 upgrade. Function Summary Reference Logic operations Program execution delay This function enables waiting for safety I/O communications to start 10-1-6 before executing the program.
Page 41: System Configuration
DeviceNet Safety System Overview DeviceNet is an open-field, multi-vendor, multi-bit network, which combines the controls in the machine and line control levels with information. The DeviceNet Safety network adds safety functions to the conventional DeviceNet standard communications protocol. The DeviceNet Safety concept has been approved by a third-party organization (TÜV Rhineland).
Page 42: Example System Configurations
Safety Remote I/O System with Safety Slaves. The Pre-Ver. 1.0 Controllers can perform safety I/O communications as a Safety Master for a maximum of 16 connections (16 Slaves) with up to 16 bytes per connection. Controllers with unit version 1.0 or later (including Controllers that support EtherNet/IP) can perform safety I/O communications as a Safety Master for a maximum of 32 connections (32 Slaves) with up to 16 bytes per connection.
Page 43 Slave. As a Standard Slave, the NE1A-series Controller enables standard I/O com- munications for a maximum of two connections with up to 16 bytes per con- nection. Four protocols (i.e., Poll, Bitstrobe, COS and Cyclic) are supported for I/O connections. The NE1A-series Controller cannot operate as a Stan- dard Master.
Page 44 Slave and standard I/O communications are performed with the Standard Master. The Safety Control System can be monitored using a Standard PLC by allo- cating the NE1A-series Controller’s status information (general status, local I/O error status, or other information) or logic operation results in the Standard PLC.
Page 45 Also, safety I/O communications between NE1A-series Controllers can be performed as illustrated in the following diagram. In the diagram, NE1A #2 is set as the slave of NE1A #1 safety connections to perform safety I/O commu- nications. The NE1A-series Controller functions as a Safety Master, Safety Slave, and Standard Slave simultaneously.
Page 46 DeviceNet or DeviceNet Safety control system via Ethernet from a machine controller or monitor computer that does not support a DeviceNet interface. This can be used to easily add a DeviceNet Safety control system to an exist- ing system. Safety controls can be monitored by accessing...
Page 47 Section 1-2 System Configuration NE1A-series Controller DeviceNet Communications Disable (Standalone) Setting When only a few I/O points are required for safety control, the NE1A-series Controller's DeviceNet communications can be disabled so that it can be used as a Standalone Controller.
Page 48 A DeviceNet Board/Card enables the Network Configurator to connect directly to the network. Remote configuration and monitoring are supported for stan- dard nodes and safety nodes on the network. When connected directly to DeviceNet, the Network Configurator forms one node on the network.
Page 49 System Configuration USB Connection to an NE1A-series Controller The Network Configurator can be used by connecting to the USB port on the NE1A-series Controller. Remote configuration and monitoring are supported for not only the Controller connected to the USB port but also for other devices on the network.
Page 50 NE1A Safety Network Controllers through the EtherNet/IP-DeviceNet Router. The Network Configurator can be at any of the following locations. • Connected via to a USB port on a Safety Network Controller on a different DeviceNet Safety network (See note 1.) •...
Page 51: System Setup Procedure
System Setup Procedure Section 1-3 System Setup Procedure The general working phases until the Safety System is operational are shown below. 1. System Design 3. Installation and Wiring 2. Programming 4. Configuration 5. User Testing 6. System Operation The NE1A-series Controller information required in each phase is described in the following sections.
Page 52 Section 1-3 System Setup Procedure Item Manual name Cat. No. Construction of a DeviceNet DeviceNet Safety System Configuration Manual Z905 Safety System Network Configurator Opera- tion (WS02-CFSC1-E) Programming Device Opera- tion Installation of Safety I/O Ter- DeviceNet Safety I/O Terminal Operation Man-...
Page 53: Specifications And Nomenclature
Nomenclature and Functions ........
Page 54: Nomenclature And Functions
Section 2-1 Nomenclature and Functions Nomenclature and Functions This section describes the part names and functions of the NE1A-series Con- trollers. 2-1-1 Nomenclature NE1A-SCPU01 (-V1) Node address switches: Sets the DeviceNet node address as a 2-digit decimal number. Indicator/display area...
Page 55 (B connector) Indicator area Baud rate switch: Terminal area Sets the DeviceNet baud rate. DeviceNet communications connector: Connects to the network communications cable. The power for communications is also supplied from this connector. The XW4G-05C1-H1-D Connector is provided for node connections.
Page 56 EtherNet/IP B connector communications Baud rate switch connector Sets the DeviceNet baud rate. DeviceNet communications connector Connects to the network communications cable. The communications power supply is also supplied from this connector. The XW4G-05C1-H1-D Connector is provided for node connections.
Page 57 Baud rate switch Terminal area EtherNet/IP B connector Sets the DeviceNet baud rate. communications connector DeviceNet communications connector Connects to the network communications cable. The communications power supply is also supplied from this connector. The XW4G-05C1-H1-D Connector is provided for node connections.
Page 58: Indicator/Display Areas
Nomenclature and Functions Section 2-1 2-1-2 Indicator/Display Areas Status Indicators The following LED indicators show the status of the NE1A-series Controller, network, and I/O circuits. • MS (module status) • NS/NS D (DeviceNet network status) • LOCK (configuration lock status) •...
Page 59 Data transmission/reception in progress. No data transmission/reception in progress. 100M Ethernet has established a 100Base-TX link. Ethernet has not established a 100Base-TX link. Ethernet has established a 10Base-T link. Ethernet has not established a 10Base-T link. : ON : Flashing...
Page 60 Seven-segment Display The 7-segment display indicates the NE1A-series Controller’s node address during normal conditions, and the error code and the node address of the error during error conditions. Also, “nd” is displayed during normal conditions if DeviceNet communications are disabled (i.e., Standalone Mode).
Page 61 Serious injury may possibly occur due to loss of required safety functions. Do not use the NE1A-series Controller's indicators for safety operations. Note The errors are indicated by the combination of the MS indicator, NS indicator, and the 7-segment display. For further details on specific meanings, refer to SECTION 12 Troubleshooting.
Page 62: Switch Settings
Any node address in the setting range can be used as long as the same address is not used by another node. If a value between 64 and 99 is set on the rotary switches, the node address can be set using a software setting on the Network Configurator.
Page 63: Devicenet Communications Connector
Nomenclature and Functions IP Address Display Switch (Only Controllers that Support EtherNet/IP) Press the IP address display switch for 1 second or longer to display at the 7- segment display the EtherNet/IP IP address that is set. For details, refer to the information on the 7-segment display in 2-1-2 Indica- tor/Display Areas.
Page 64: Input/Output Terminals And Internal Connections
Safety input terminals T0 to T3 Test output terminals used to connect with safety inputs IN0 to IN15. Each test output terminal outputs a different test pulse pattern. Terminal T3 also supports a current monitoring function for the output signal, for example, for a muting lamp.
Page 65 Safety input terminals T0 to T3 Test output terminals used to connect with safety inputs IN0 to IN19. Each test out- put terminal outputs a different test pulse pattern. Terminal T3 also supports a cur- rent monitoring function for the output signal, for example, for a muting lamp.
Page 66 Safety input terminals T0 to T3 Test output terminals used to connect with safety inputs IN0 to IN15. Each test out- put terminal outputs a different test pulse pattern. Terminal T3 also supports a cur- rent monitoring function for the output signal, for example, for a muting lamp.
Page 67 Safety input terminals T0 to T3 Test output terminals used to connect with safety inputs IN0 to IN19. Each test out- put terminal outputs a different test pulse pattern. Terminal T3 also supports a cur- rent monitoring function for the output signal, for example, for a muting lamp.
Page 68: Specifications
Serial interface USB Ver. 1.1 Weight 460 g max. (NE1A-SCPU01-EIP: 570 g max.) Note V0 to G0: For internal logic circuits, V1 to G1: For external input devices and test outputs, V2 to G2: For external output devices. NE1A-SCPU02(-EIP) Item Specifications DeviceNet supply voltage 11 to 25 VDC (Supplied from communications connector.)
Page 69: Devicenet Communications Specifications
Communications Conforms to DeviceNet. protocol Connection method The multidrop and T-branch connections can be combined (for main line and branch lines). Baud rate 500 kbits/s, 250 kbits/s, 125 kbits/s Communications Special cable with 5 lines (2 communications lines, 2 power lines, 1 shield line)
Page 70: I/O Specifications
Leakage current 0.1 mA max. IMPORTANT If a safety output is set as a safety pulse output, an OFF pulse signal (pulse width: 580 µs) will be output to diagnose the output circuit when the safety output turns ON. Check the input response time of the control device con- nected to the NE1A-series Controller to be sure that this output pulse will not cause malfunctions.
Page 71: Installation And Wiring
Wiring I/O Devices ........
Page 72: Installation
NE1A-series Safety Network Controller System and to fully exploit the system’s capabilities. Installation and Storage Environment Do not use or store the NE1A-series Controller in any of the following loca- tions. • Locations subject to direct sunlight • Locations subject to temperatures or humidity outside the ranges speci- fied in the specifications •...
Page 73: Mounting To The Control Panel
Controller) to prevent it from falling off the DIN Track because of vibration. • Provide sufficient space around the NE1A-series Controller, at least 5 mm at the sides and at least 50 mm at the top and bottom, for ventilation and wiring.
Page 74 Section 3-1 Installation Mounting To ensure proper ventilation, mount the NE1A-series Controller as shown in the following diagram. Bottom Do not mount the NE1A-series Controller as in the following diagrams. Bottom Bottom Bottom Bottom...
Page 75 Installation Section 3-1 ■ DIN Track Mounting Bracket Position for the NE1A-SCPU01(-V1) DIN Track Mounting Bracket ■ DIN Track Mounting Bracket Position for the NE1A-SCPU02 DIN Track Mounting Brackets...
Page 76 Installation Section 3-1 ■ DIN Track Mounting Bracket Position for the NE1A-SCPU01-EIP DIN Track Mounting Bracket ■ DIN Track Mounting Bracket Position for the NE1A-SCPU02-EIP DIN Track Mounting Brackets...
Page 77: Dimensions And Weight
Section 3-1 Installation 3-1-3 Dimensions and Weight Dimensions ■ NE1A-SCPU01(-V1) 99.4 (99) 111.1...
Page 78 Installation Section 3-1 ■ NE1A-SCPU02 135.6 (99) 111.1...
Page 79 Section 3-1 Installation ■ NE1A-SCPU01-EIP (99) 111.1...
Page 80 Section 3-1 Installation ■ NE1A-SCPU02-EIP 158.2 (99) 111.1 Weight Model Weight NE1A-SCPU01(-V1) 460 g max. NE1A-SCPU02 690 g max. NE1A-SCPU01-EIP 570 g max. NE1A-SCPU02-EIP 800 g max.
Page 81: Wiring
• Be careful not to get your fingers caught when attaching connectors to the plugs on the NE1A-series Controller. !WARNING Serious injury may possibly occur due to loss of required safety functions. Wire the con- ductors correctly and verify the operation of the NE1A-series Controller before using the Controller system in actual operation.
Page 82: Wiring The Power Supply And I/O Lines
Confirm the dimensions beforehand.) Use wires of the same diameter if two-wire pin terminals are used. • When wiring with pin terminals, be sure to insert pin terminals all the way Note into the terminal block.
Page 83 Power Supply Selection Use a DC power supply satisfying the following requirements. • The secondary circuits of the DC power supply must be isolated from the primary circuit by double insulation or reinforced insulation. • The DC power supply must satisfy the requirements for class 2 circuits or limited voltage/current circuits defined in UL 508.
Page 84: Wiring I/O Devices
24 VDC 4 mA, 24 VAC ■ Devices with PNP Semiconductor Outputs (Current Sourcing) Example: Light curtains A PNP semiconductor output signal from this type of device is input to the NE1A-series Controller’s safety input terminal. 4.5 mA typical 24 VDC...
Page 85 • Be sure to separate I/O cables from high-voltage/current lines. • Use a total I/O communications cable length of 30 m or less. • Do not apply the power supply to the test output terminals. Doing so may result in product damage or burning.
Page 86 Serious injury may possibly occur due to loss of required safety functions. Ground the 0- V line of the power supply for external output devices so that the devices do NOT turn ON when the safety output line or the test output line is grounded.
Page 87 S1: Emergency stop switch S2 Reset switch KM1 and KM2: Contactors M: Motor Note Connect a 24-VDC power supply to terminals V0 and G0 (power supply termi- nals for internal circuits). Note This example shows an NE1A-SCPU01(-V1)(-EIP) Controller’s terminal lay- out.
Page 88 E1 and E2: 24-VDC power supplies S11 and S12: Two-hand switches KM1 and KM2: Contactors M: Motor Note Connect a 24-VDC power supply to terminals V0 and G0 (power supply termi- nals for internal circuits). Note This example shows an NE1A-SCPU01(-V1)(-EIP) Controller’s terminal lay- out.
Page 89 S1: External test switch S2: Lockout reset switch KM1 and KM2: Contactors M: Motor Note Connect a 24-VDC power supply to terminals V0 and G0 (power supply termi- nals for the internal circuits). Note This example shows an NE1A-SCPU01(-V1)(-EIP) Controller’s terminal lay- out.
Page 90 Example of Connecting a User Mode Switch E1 and E2: 24 VDC power supplies S1: User mode switch Note Connect a 24-VDC power supply to terminals V0 and G0 (power supply termi- nals for internal circuits). Note This example shows an NE1A-SCPU01(-V1)(-EIP) Controller’s terminal lay-...
Page 91: Devicenet Wiring
Stickers are placed on the communication connectors based on the color of each communications wire. By matching the communications wire colors with the connector sticker colors, you can check to see if wires are in the correct locations. The colors of the wires are as follows:...
Page 92: Ethernet (Ethernet/Ip) Network Installation
• Do not install Ethernet equipment near sources of noise. If a noisy envi- ronment is unavoidable, take adequate measures against noise interfer- ence, such as installing network components in grounded metal cases or using optical cable in the system.
Page 93 Connector terminal (Shield) • Press the cable connector in firmly until it locks into place at both the switching hub and the NE1A-series Controller. • Do not lay the twisted-pair cable together with high-voltage lines. • Do not lay the twisted-pair cable near devices that generate noise.
Page 94 Note NE1A-series Controller link settings must match the communications mode settings of connected switching hubs. If they do not match, links will be unsta- ble and normal communications will not be possible. For EtherNet/IP I/O com- munications (tag data link communications) with an EtherNet/IP standard originator, it is recommended that auto-negotiation or 100M full-duplex com- munications be set for the Controller and the switching hubs.
Page 95 35 mm 1,2,3... 1. Lay the twisted-pair cable. 2. Connect the cable to the switching hub. Be sure to press in the cable until it locks into place. This procedure should only be performed by qualified personnel. 3. Connect the twisted-pair cable to the connector on the NE1A-series Con- troller.
Page 97: Devicenet Communications Functions
Software Settings ........
Page 98: Initial Setting
Any node address in the setting range can be used as long as the same address is not used by another node. If a value between 64 and 99 is set on the rotary switches, the node address can be set using a software setting on the Network Configurator.
Page 99 The NE1A-series Controller’s baud rate can be set automatically to match the baud rate of the master on the network. The baud rate must be set in at least one Safety Master or Standard Master on the network. After turning ON the power, the baud rate is set when establishing communications, and the baud rate setting is stored until the next time power is turned ON.
Page 100: Software Settings
The default is to have DeviceNet communications enabled (normal mode). Make the setting from the Network Configurator. After the setting has been made, a reset command will be sent from the Network Configurator to the NE1A-series Controller to enable the setting.
Page 101: Network Status Indication
Section 4-2 Network Status Indication Network Status Indication Network status is displayed on the NS/NS D indicator on the NE1A-series Controller. Refer to 2-1-2 Indicator/Display Areas for details. Note Error contents are shown through combinations of the MS and NS indicators, and seven-segment display.
Page 102: Remote I/O Allocations
Network Configurator. I/O of the des- tination communications slave and the I/O area for an NE1A-series slave are displayed as I/O tags. Using I/O tags allows a user to program without being conscious of the NE1A-series Controller’s memory addresses.
Page 103: Remote I/O Area Attributes
Remote I/O Area Attributes The NE1A-series Controller’s remote I/O area has the following attributes. All values in the safety remote I/O area will be cleared if the operating mode is changed. If a communications error occurs, all data for the connection for which the error occurred will be cleared.
Page 104: Remote I/O Area Data Configuration
I/O monitor data, and I/O data, in that order. The status data can be collected in the PLC to create a monitoring sys- tem. The data can also be configured of only status data, only local I/O moni- tor data, or only I/O data.
Page 105 Word User registered. Safety DWORD (Double Word) I/O Tags Double User registered. Safety word • NE1A-series Controllers with Unit Version 1.0 or Later (Including Control- lers that Support EtherNet/IP) Data type Name/format Data size Setting method using Attribute Network Configurator...
Page 106 (1) For the NE1A-SCPU01-V1(-EIP), N = 2 and M = 1. For the NE1A- SCPU02(-EIP), N = 5 and M = 2. The sizes of the local input status, test output/muting lamp status, and local input monitor status data can be specified in bytes.
Page 107 Section 4-3 Remote I/O Allocations Settings from Network Configurator (Unit Version 1.0 or Later, Including Con- trollers that Support EtherNet/IP) The following table shows the remote I/O area arrangement when the above settings are made. Byte Bit 7 Bit 6...
Page 108 Remote I/O Allocations Section 4-3 The following table shows the remote I/O area arrangement when the above settings are made. Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0 Local Input Status 1 (1 byte)
Page 109 For Controllers that support EtherNet/ IP, the status of this bit is an AND of the DeviceNet or Ether- Net/IP standard communications status. Safety I/O Communications Error Sta- Indicates if there is any error in Safety I/O communications.
Page 110 Bit 4 Bit 5 When the NE1A-series Controller is Operating as a Safety Master and a Safety Slave • Example: Monitoring NE1A-series Controller Safety I/O Communications Error and Status Flags from the PLC (when a dA Error Occurs)
Page 111 Bit 4 Bit 5 • Example: Monitoring NE1A-series Controller Safety I/O Communications Error and Status Flags from the PLC (when d5 and d6 Errors Occur) Communications Communications established at d6 error at established at all...
Page 112 12 status 11 status 10 status status status ON: Normal, OFF: Error Local Input Status 1 (1 Byte, Controllers with Unit Version 1.0 or Later, Including Con- trollers that Support EtherNet/IP) Attribute: Safety Data Byte Bit 7 Bit 6 Bit 5...
Page 113 5 status 4 status nection detected status ON: Normal, OFF: Error Local Input Monitor 1 (1 Byte, Controllers with Unit Version 1.0 or Later, Including Con- trollers that Support EtherNet/IP) Attribute: Safety Data Byte Bit 7 Bit 6 Bit 5...
Page 114 ON: ON, OFF: OFF Note The results of appraising input data is given for the local input monitor status. The status may not be the same as the status of the connected input device if channel mode is set or an error occurs.
Page 115 User data User data User data User data User data User data Bit 31 Bit 30 Bit 29 Bit 28 Bit 27 Bit 26 Bit 25 Bit 24 Unused bits among the above user-registered I/O tags will be fixed at 0.
Page 116: Safety Master Function
Controller’s I/O memory based on the settings made from the Network Configurator. In the Logic Editor, slave I/O is displayed as I/O tags. Using these I/O tags allows a user to program without being aware of specific memory addresses in the NE1A-series Controller.
Page 117: Safety I/O Connection Settings
4-4-2 Safety I/O Connection Settings Safety connections must be set in order to perform safety I/O communications between the NE1A-series Controller and the Safety Slaves. A “connection” is a logical communications path for a master and slave to communicate with each other.
Page 118 Some slaves have multiple I/O data (I/O assembly data) internally and the data to be communicated from them can be selected. Here, the data to allo- cated in the NE1A-series Controller can be specified from the data in the reg- istered Safety Slave.
Page 119: Stopping/Resetting Communications After
Safety System Configuration Manual (Cat. No. Z905) for information on the net- work reaction time. The minimum set for the EPI is either the cycle time of the Safety Network Con- • troller or the cycle time of the Safety Slaves (always 6 ms), whichever is greater.
Page 120 Network Configurator to send a command to restart communica- tions. It is also possible to write a logic routine in the user program in advance to turn ON the specified Safety I/O Communications Restart Flag and restart communications with a specified trigger bit.
Page 121 Communications restart tag for all connections When these tags have been set in the user program in advance as I/O com- munications restart conditions, I/O communications can be restarted with these tags by turning ON (OFF → ON) the specified condition.
Page 122: Safety Slave Function
The following steps are required in order for the NE1A-series Controller to perform safety I/O communications as a Safety Slave. 1. Creation of I/O data (safety slave I/O) to use as a Safety Slave 2. Registration in the Safety Master 3.
Page 123: Creating I/O Data (Safety Slave I/O) To Use As Safety Slave
• Local Output Status • Test Output/Muting Lamp Status • If the I/O type of the Safety Slave I/O is set to Slave IN for a NE1A-series Controller with unit version 1.0 or later (including Controllers that support EtherNet/IP), the following local I/O monitor data can also be included in the I/O data.
Page 124 Data output to the network from the Safety Master. Setting I/O Tags Set the input data blocks and output data blocks to use in the program for the Safety Slave I/O. Multiple data blocks can be set for Safety Slave I/O. The size of the data block can be selected from BOOL (1 byte), BYTE (1 byte), WORD (2 bytes), or DWORD (4 bytes).
Page 125 For the NE1A-SCPU01-V1(-EIP), N = 2 and M = 1. For the NE1A-SCPU02(- EIP), N = 5 and M = 2. The sizes of the local input status and test output/mut- ing lamp status data can be specified in bytes.
Page 126: Standard Slave Function
4-6-2 Creating I/O Data (Slave I/O) to Use as Standard Slave The I/O data to be used for the DeviceNet Slave must be created in order for an NE1A-series Controller to perform standard I/O communications as a Standard Slave. The memory blocks for this I/O data are called Slave I/O.
Page 127 • Local Output Status • Test Output/Muting Lamp Status • If the I/O type of the Safety Slave I/O is set to Slave IN for a NE1A-series Controller with unit version 1.0 or later (including Controllers that support EtherNet/IP), the following local I/O monitor data can also be included in the I/O data.
Page 128 For the NE1A-SCPU01-V1(-EIP), N = 2 and M = 1. For the NE1A-SCPU02 (-EIP), N = 5 and M = 2. The sizes of the local input status and test output/ muting lamp status data can be specified in bytes.
Page 129 Standard Slave Function Note For the NE1A-SCPU01-V1(-EIP), N = 2. For the NE1A-SCPU02(-EIP), N = 5. The sizes of the local input status and local input monitor status data can both be specified in bytes. !WARNING Serious injury may possibly occur due to loss of required safety functions.
Page 131: Ethernet/Ip Communications
5-1-1 Setting the IP Address ........
Page 132: Connecting To Ethernet
Connecting to Ethernet 5-1-1 Setting the IP Address You can use either of the following methods to set the IP address for an NE1A-series Controller that supports EtherNet/IP. Method 1: Acquiring the IP Address from a BOOTP Server (This is the default mode for NE1A-series Controllers that support Ether- Net/IP.)
Page 133: Tcp/Ip Settings
4. Select Tools - TCP/IP Settings. The Setup TCP/IP Configuration Dialog Box will be displayed. The default settings are given in the dialog box shown below. 5. In the Target IP Address, set the present IP address for the applicable NE1A-series Controller.
Page 134 0. These settings must be made when using an address conversion method other than the IP address table method. If no subnet mask is set, or if an illegal value is set, the following values will be used depending on the IP address class.
Page 135 Section 5-1 Connecting to Ethernet The following table shows the various Unit settings when only the IP Address Display/Setting Area is set, and the other TCP/IP Configuration settings are left at their default values. Setting Operating status IP address Set with the Network Configurator.
Page 136: Standard Target Function
5-2-2 Creating I/O Data (Target I/O) to Use as Standard Target The I/O data to be used for the Standard Target must be created in order for an NE1A-series Controller to perform standard I/O communications as a Standard Target.
Page 137 IMPORTANT When connected to an OMRON CS/CJ-series EtherNet/IP Communications Unit, I/O communications for EtherNet/IP are set in 2-byte increments. When creating an odd number of bytes of I/O data, add one byte to the I/O tag to make it an even number.
Page 138 Data C Data D IMPORTANT If Safety Input Slave data is to be handled by the Originator using Target I/O communications, the data must be set for DeviceNet Safety I/O communica- tions. For details on making the settings, refer to 4-4-2 Safety I/O Connection...
Page 139 Setting Local I/O Monitor Data If the I/O type of the Target I/O is set to Target IN for a NE1A-series Controller the following local I/O monitor information can be added to the transmission data after the status information.
Page 141: Explicit Message Communications
Receiving Explicit Messages ........
Page 142: Receiving Explicit Messages
Controller. Refer to Appendix 3: Explicit Messages for details on the services that are available. The format shown here for explicit messages is the format used on the net- work. Refer to the operation manual of the Standard Master for specific setting methods for each Standard Master.
Page 143 Safety Remote Input Area: 0 to 511 Safety Remote Output Area: 0 to 511 The I/O addresses of memory information that has been read can be checked on the Memory Info. Tab Page of the Edit Device Parameters Dialog Box for the NE1A-series Controller. I/O name...
Page 144 For the NE1A-SCPU01 or NE1A-SCPU01-V1(-EIP), status can be read for 16 terminals, i.e., safety input terminals No. 0 to 15. For the NE1A-SCPU02 (-EIP), status can be read for 40 terminals, safety input terminals No. 0 to 39. • Local Outputs and Test Outputs (2 Bytes)
Page 145 Receiving Explicit Messages Section 6-1 Error Code (Response) The following error codes defined in DeviceNet may be returned. Response Error name Cause code 08FF Service not Error in the service code. supported 13FF Not enough data The data is shorter than the specified size.
Page 146: Sending Explicit Messages
This function can be used only with DeviceNet. User-registered messages are sent over the network when user-specified trig- ger conditions are met. This can be used to notify monitoring and control devices or as a method for specifying outputs to display devices.
Page 147: Restrictions
6-2-3 Restrictions • One address can be set in the user program for the trigger address. • The NE1A-series Controller’s internal I/O memory is sent as a response to an explicit message. Explicit messages can be sent from a user pro- gram in the Controller, but internal information in the Controller cannot be used as send message data.
Page 149: I/O Control
I/O Power Monitor ........
Page 150: Common Functions
An optional name consisting of up to 32 characters can be registered in the NE1A-series Controller for each I/O terminal using the Network Configurator. These I/O comments can be used in the Function List of the Logic Editor as I/O tags, enabling easy conceptualization of what is actually being controlled and simplifying programming.
Page 151: I/O Power Monitor
7-1-2 I/O Power Monitor The I/O power supply input can be monitored to confirm if it is normal. If an I/O terminal on the NE1A-series Controller is set to any setting other than Not Used and the normal power supply voltage is not input, the following items will be displayed on the 7-segment display: •...
Page 152 Common Functions If the alarm threshold (Threshold Maintenance Counter) is set to 0, the Con- troller will not compare the count or time PV to the alarm threshold SV. Monitoring Operations from the Network Configurator Any of the following methods can be used to monitor the number of contact operations in the local input status, test output status, or local output status.
Page 153: Total On Time Monitor Function Unit Ver. 1.0 Or Later
This function can be used with Controllers with unit version 1.0 or later (including Controllers that support EtherNet/IP). It times how long a local input, test output, or local output is ON and stores that total ON time internally in non-volatile memory.
Page 154 ■ Calculating the Total ON Time with 1.5-s ON Pulses In figure C, the bit is actually ON for 1.5 s × 2 = 3 s, but the bit is ON four times when the status is checked, so the total ON time is measured as 4 s.
Page 155 (Threshold Maintenance Counter) can be set for each local input, test output, and local output terminal. If the alarm threshold (Threshold Maintenance Counter) is set to 0, the Con- troller will not compare the count or time PV to the alarm threshold SV.
Page 156 Section 7-1 Monitoring the Total ON Time from the Network Configurator Any of the following methods can be used to monitor the total ON time in the local input status, test output status, or local output status. 1. Select the device and select Device – Maintenance information from the menu bar.
Page 157: Safety Inputs
The NE1A-SCPU01(-V1)(-EIP) is equipped with 16 safety input terminals. The NE1A-SCPU02(-EIP) is equipped with 40 safety input terminals. By selecting the setup and wiring based on the types of input devices to be connected or the safety level to be achieved, the NE1A-series Controller can flexibly handle various applications.
Page 158: Input Channel Mode Setting
Select the test output terminal to use as the test source for the safety input when the input channel mode is set to Test pulse from test output. If short cir- cuit detection between input wiring lines is necessary, specify a different test output terminal.
Page 159: Dual Channel Mode Setting
For two inputs set in Dual Channel Mode, the time is monitored from a change in the value of one input to a change in the value of the other input (discrep- ancy time). When the value of the other input does not change within the set discrepancy, it is regarded as an error.
Page 160 Error Status Status Note The NE1A-series Controllers supports function blocks with functionality equiv- alent to Dual Channel Mode. If Dual Channel Mode is set in a function block, then the safety input terminal can be set to Single Channel Mode.
Page 161: Error Handling
• I/O tags corresponding to safety input terminal pairs for which errors have been detected are made inactive. • The LED indicator of the safety input with the error lights red, and the LED indicator of the other input flashes red.
Page 162: Test Outputs
• The NE1A-series Controller will continue to operate. Error Latch Time Setting The time to latch the error state when an error occurs in a safety input termi- nal or test output terminal can be set. The error state will continue until the error latch time passes even if the cause of the error is momentarily removed.
Page 163: Safety Outputs
(when the output is ON or OFF), ground faults, and short circuits between output signals. IMPORTANT If a safety pulse output is set, an OFF pulse signal (pulse width: 580 µs) will be output to diagnose the output circuit when the safety output turns ON.
Page 164: Error Handling
Section 7-4 Safety Outputs Reflecting Output Data from Output I/O Tags to Safety Output Terminals Output I/O tag data is reflected in the safety output terminals according to the channel mode, as shown in the following tables. Channel Mode Output tag...
Page 165 Safety Outputs Error Latch Time Setting The time to latch the error state when an error occurs in a safety output circuit can be set. The error state will continue until the error latch time passes even if the cause of the error is momentarily removed. When monitoring errors from a monitoring system, take the monitoring interval into account when setting the error latch time.
Page 167: Programming
Program Capacity ........
Page 168: Outline Of Programming
The NE1A-series Safety Network Controller is programmed by starting a Logic Editor from the Network Configurator. As shown below, the Logic Editor consists of a Function List where function blocks, I/O tags, and other program- ming elements are registered and a workspace where programming is actu- ally performed.
Page 169 Section 8-1 Outline of Programming ■ Input Tags Input tags reflect the status of inputs in the following I/O areas. • Input area from the NE1A-series Controller’s local terminals • Input area from safety slaves registered as communications partners • I/O area reflected from Safety Master data •...
Page 170: Program Capacity
Always verify that the safety-related signals used in safety-related logic meet applicable standards and regulations. Input only safety input signals to function blocks. It is the user's responsibility to verify that the proper sources for signals used in conjunction with these function blocks and the overall safety logic imple- mentation adhere to relevant safety standards and regulations.
Page 171: Function Block Overview
Function Block Overview Function Block Overview User programming for the NE1A-series Controller is accomplished using func- tion blocks. Various safety applications can be achieved by using the function blocks described in this section to program operation to be compliant with safety standards.
Page 172: Function Block Editing
Section 8-3 Function Block Editing Function Block Editing Editing of function blocks can be used to set parameters, add optional I/O, and add comments according to the application. Tabs: Function block parameters Out point Setting, In/Out Settings Comments 8-3-1 Function Block Parameter Settings The following parameters can be set for function blocks depending on the user application.
Page 173 Section 8-3 Function Block Editing Setting: Dual Channel Complementary Input 1 Input 2 Output Enable (NC) (NO) Setting: Dual Channel Equivalent (2 Pairs) Input 1 Input 2 Input 3 Input 4 Output (NC) (NC) (NC) (NC) Enable Setting: Dual Channel Complementary (2 Pairs)
Page 174 Section 8-3 Function Block Editing Discrepancy Time If the function block input type is set to Dual Channel Equivalent or Dual Channel Complementary, the discrepancy time (i.e., the time between changes in the inputs) can be evaluated. The time between when one of the dual-channel inputs changes until the other one changes is monitored.
Page 175: I/O Settings
Error Synchronization Time Setting If the function block input type is set to Dual Channel Equivalent (2 Pairs) or Dual Channel Complementary (2 Pairs) for the Safety Gate Monitoring func- tion block, the synchronization time (i.e., the time between changes in the input pairs) can be evaluated.
Page 176 Fault Present Setting Fault Present is a diagnostic status bit supported in some function blocks by selecting the checkbox located on the In/Out Setting or Out Point Tab Page of the function block properties. If the Fault Present checkbox is selected, an additional Fault Present output will be displayed on the function block.
Page 177: Command Reference: Logic Functions
Default Maximum Number of Inputs General Description An AND of the input conditions will be output. Up to eight input conditions can be evaluated. Optional Input Settings The number of inputs can be increased on the In/Out Setting Tab Page in the function block property dialog box.
Page 178 Output 1 0: OFF, 1: ON Truth Table for Two-input AND Evaluation Input 1 Input 2 Output 1 0: OFF, 1: ON, x: Either ON or OFF Truth Table for Three-input AND Evaluation Input 1 Input 2 Input 3 Output 1...
Page 179 Input 1 Input 2 Input 3 Input 4 Input 5 Input 6 Output 1 0: OFF, 1: ON, x: Either ON or OFF Truth Table for Seven-input AND Evaluation Input 1 Input 2 Input 3 Input 4 Input 5 Input 6...
Page 180 Default Maximum Number of Inputs General Description An OR of the input conditions will be output. Up to eight input conditions can be evaluated. Optional Input Setting The number of inputs can be increased on In/Out Setting Tab Page in the function block property dialog box.
Page 181 Section 8-4 Truth Table for Three-input OR Evaluation Input 1 Input 2 Input 3 Output 1 0: OFF, 1: ON, x: Either ON or OFF Truth Table for Four-input OR Evaluation Input 1 Input 2 Input 3 Input 4 Output 1...
Page 182: Exclusive Or (Exor)
Input 3 Input 4 Input 5 Input 6 Input 7 Input 8 Output 1 0: OFF, 1: ON , x: Either ON or OFF 8-4-4 Exclusive OR (EXOR) Diagram General Description An exclusive OR of the input conditions will be output.
Page 183: Exclusive Nor (Exnor)
Output 1 0: OFF, 1: ON 8-4-5 Exclusive NOR (EXNOR) Diagram General Description An exclusive NOR of the input conditions will be output. Truth Table Truth Table for Exclusive NOR Evaluation Input 1 Input 2 Output 1 0: OFF, 1: ON...
Page 184 (including Controllers that support EtherNet/IP). When the input condition to the Reset Set Flip-Flop function block is turned ON, that ON status is maintained (latched) in the function block and the ON output is maintained at the Output Enable signal.
Page 185: Comparator Unit Ver. 1.0 Or Later
00000001 (Input 1 is ON.) (Individual bits correspond to Input 1 to Input 8) Optional Input Settings The number of inputs can be increased on the In/Out Setting Tab Page in the function block property dialog box. Parameter Setting range...
Page 186 Input 8 0: OFF; 1: ON Note “= CD for Input n” indicates that the Comparator input signals are the same as the comparison data. “≠ CD for Input n” indicates that the Comparator input signals are not the same as the comparison data.
Page 187 The horizontal broken lines in the above diagram represent the comparison data for each input. 1. Output Enable turns ON when all of the input signals match the compari- son data. 2. Output Enable turns OFF when any of the input signals does not match the comparison data.
Page 188: Command Reference: Function Blocks
Maximum Number of Inputs General Description The Output Enable signal will turn ON if the Reset signal is correctly input while the input condition to the Reset function block is ON. This function block can be used to prevent the machine from automatically reset, e.g., when the power to the NE1A-series Controller is turned ON, when...
Page 189 Reset Output Output Enable Enable Number of Inputs Setting The number of inputs can be increased on the In/Out Setting Tab Page in the function block property dialog box. Parameter Setting range Default setting Number of inputs 2 to 8 (Optional Input Settings) Optional Output Settings The outputs shown below can be used in the program.
Page 190 Monitored input Optional Input N Reset Output Enable Static Release Reset Req. Indication Idle to RUN Reset Signal set to Rising Edge: Unit Ver. 1.0 or Later Monitored input Optional Input N Reset Output Enable Static Release Reset Req. Indication...
Page 191: Restart
Maximum Number of Inputs General Description The Output Enable signal will turn ON if the Reset signal is correctly input while the input condition to the Restart function block is ON. This function block can be used to prevent the machine from automatically restarting, e.g., when the power to the NE1A-series Controller is turned ON,...
Page 192 Reset Output Output Enable Enable Number of Inputs Setting The number of inputs can be increased on the In/Out Setting Tab Page in the function block property dialog box. Parameter Setting range Default setting Number of inputs 2 to 8 (Optional Input Settings) Optional Output Settings The outputs shown below can be used in the program.
Page 193: Emergency Stop Pushbutton Monitoring (E-Stop)
Monitored input Optional Input N Reset Output Enable Static Release Reset Req. Indication Idle to RUN Restart Signal set to Rising Edge Unit Ver. 1.0 or Later Monitored input Optional Input N Reset Output Enable Static Release Reset Req. Indication...
Page 194 The Emergency Stop Pushbutton Monitoring function block allows the user to monitor an emergency stop pushbutton switch. The Output Enable signal will turn ON if the input from the emergency push- button being monitored is active. The Output Enable signal will turn OFF if the input is inactive or if an error is detected for the function block.
Page 195 Output Fault Error output condition Enable Present Discrepancy Discrepancy Remove the cause of the error error Error output: ON and then do the following: (safety state) 1. Make the inputs inactive and then active again. 2. Or change the NE1A-series Controller’s operating mode...
Page 196: Light Curtain Monitoring
The Light Curtain Monitoring function block monitors a type-4 safety light cur- tain. The Output Enable signal will turn ON if the input from the safety light curtain being monitored is active. The Output Enable signal will turn OFF if the input is inactive or if an error is detected for the function block.
Page 197 Command Reference: Function Blocks Optional Output Setting The following error output can also be used in programming. To enable this optional output, select the checkbox on the Out Point Tab Page of the function block properties dialog box. • Discrepancy Error Fault Present Output Setting Fault Present output can also be used in programming.
Page 198: Safety Gate Monitoring
Safety gate status is monitored using an input signal from a safety door switch or safety limit switch connected to the door. The Output Enable signal will turn ON if the input from the switch being mon- itored is active. The Output Enable signal will turn OFF if the input is inactive...
Page 199 (after removing the cause of the error). The Function Test Required Signal from the Safety Gate Monitoring function block will turn ON when a safety gate test is required and it will remain ON until the safety gate test has been completed normally. Set Parameters...
Page 200 Command Reference: Function Blocks Optional Output Settings The following outputs can also be used in programming. To enable any of these optional outputs, select the checkbox on the Out Point Tab Page of the function block properties dialog box. Discrepancy Error Pair 1...
Page 201 Section 8-5 Command Reference: Function Blocks Setting: Two Dual Channel Equivalent (2 Pairs) Input 1 Input 2 Input 3 Input 4 Output (pair 1-NC) (pair 1-NC) (pair 2-NC) (pair 2-NC) Enable 0: OFF, 1: ON Setting: Two Dual Channel Complementary (2 Pairs)
Page 202 Note If a discrepancy error occurs in one of the pairs when set to Dual Channel Equivalent (2 pairs) or Dual Channel Complementary (2 pairs), to reset the error make input pairs 1 and 2 both inactive and then active.
Page 203: Two-Hand Control
Input1 (NC) Input2 (NC) Output Enable Discrepancy Error Fault Present Idle to RUN Discrepancy time Discrepancy time Dual Channel Equivalent (2 pairs), Function Test Set to Disabled Input1 (Pair1-NC) Input2 (Pair1-NC) Input3 (Pair2-NC) Input4 (Pair2-NC) Output Enable Sync. Error Fault...
Page 204 EN 574. The Output Enable signal will turn OFF if the inputs from the two-hand switch do not satisfy the requirements of EN 574, an input is inactive, or if an error is detected for the function block.
Page 205 RUN Mode. Note The Output Enable signal will not turn ON if the synchronization time require- ment is not met (i.e., operation inputs for both hands must be completed within 500 ms), but this is not considered an error.
Page 206: Off-Delay Timer
OFF-delay Timer Diagram General Description The OFF-delay Timer function block performs a timer operation for an OFF delay set in 10-ms increments. The range for this delay is from 0 ms to 300 s. Set Parameters Parameter Setting range Default setting...
Page 207: On-Delay Timer
ON-delay Timer Diagram General Description The ON-delay Timer function block performs a timer operation for an ON delay set in 10-ms increments. The range for this delay is from 0 ms to 300 s. Set Parameters Parameter Setting range Default setting...
Page 208: User Mode Switch
1-of-N type switch (i.e., one of N contacts is ON). The function block supports a maximum of eight inputs and corresponding outputs. The output corresponding to the input that is active is turned ON. If an error is detected for the function block, however, all outputs will turn OFF.
Page 209 If more than one input is ON, the output corresponding to the first input to turn ON will turn ON for 2 s. If more than one input turns ON in the same NE1A- series Controller cycle, then all outputs will turn OFF.
Page 210: External Device Monitoring (Edm)
If the input signal turns ON, the Output 1 and Output 2 signals will turn ON. When this occurs, the status of the feedback signal must change within the specified time.
Page 211: Routing
General Description The Routing function block routes one input signal to a maximum of eight out- put signals. It is used to output a signal to more than one output tag. Optional Output Settings The number of outputs can be increased on the In/Out Setting Tab Page in the function block property dialog box.
Page 212: Muting Unit Ver. 1.0 Or Later
Muting is enabled by detecting that the robot is in a safe location using a limit switch or other device. Use this mode to temporarily disable the light curtain when the operator...
Page 213 If an input is normally received for the Muting Signal when the Muting function block is in a normal state, the AOPD input is ON (the light curtain is not obstructed), and the Output Enable is ON, muting status will be enabled and Muting Status will turn ON.
Page 214 The override will be stopped when any of the following conditions is met and Muting Status and Override Status will turn OFF. • All of the muting signals are ON (i.e., the muting sensor is not detecting a workpiece). • The maximum override time has expired.
Page 215 (i.e., muting sensors) exceeds the synchronization time that has been set. If the AODP input turns OFF (i.e., if the light curtain is obstructed) while there is a synchronization error, Output Enable will turn OFF and Fault Present will turn The condition for a synchronization error are give for each muting mode in the following table.
Page 216 AOPD input turning OFF is detected while muting signal 11 is ON. muting signal 11 is OFF. Parallel Muting with 2 Sensors Muting signal 11 is detected, and then mut- • Muting signal 12 is detected before muting ing signal 12 is detected.
Page 217 1. In the block diagram above, the light is not interrupted between MS11 and MS12 and the light curtain, so the Output Enable signal is ON. 2. As the workpiece moves to the right and MS11 and MS12 go ON in order, muting is enabled.
Page 218 Synchronization time setting time The default setting is 3 s. D1 must satisfy formula 1 and d1 must satisfy formula 2 in order for the muting function to be operate effectively. These distance settings must prevent a passing person from enabling the muting function. Also, the light curtain and muting sensors must be setup so that a workpiece passes by all of the muting sensors before the next workpiece arrives at the muting sensors.
Page 219 Section 8-5 Command Reference: Function Blocks ■ Timing Chart Normal Operation AOPD Input 1 (NC) AOPD Input 2 (NC) Muting Signal 11 Muting Signal 12 Output Enable Muting Status Fault Present Idle to RUN Synchronization time...
Page 220 Section 8-5 Command Reference: Function Blocks Synchronization Error AOPD Input 1 (NC) AOPD Input 2 (NC) Muting Signal 11 Muting Signal 12 Output Enable Muting Status Synchroni- zation Error Fault Present Synchronization time (set value) Sequence Error AOPD Input 1 (NC)
Page 221 MS12, MS21, and MS22 and the light curtain, so the Output Enable signal is ON. 2. As the workpiece moves to the right and MS11 and MS12 go ON in order, muting is enabled, and the Muting Status goes ON.
Page 222 Section 8-5 Command Reference: Function Blocks D2 must satisfy formula 3, D3 must satisfy formula 4, and d5 must satisfy for- mula 5 in order for the muting function to operate effectively. These distance settings must prevent a passing person from enabling the muting function.
Page 223 ON. 2. For the entrance, as the workpiece moves to the right and MS11 and MS12 go ON in order (MS22 and MS21 go ON in order at the exit), muting is en- abled, and the Muting Status goes ON.
Page 224 Section 8-5 Command Reference: Function Blocks Setup Distances The setup distance requirements are the same as for Sequential Muting (For- ward Direction). ■ Timing Chart Entrance AOPD Input 1 (NC) AOPD Input 2 (NC) Muting Signal 11 Muting Signal 12...
Page 225 In the above example, limit switch 1 is wired to IN0 on the NE1A-series Con- troller and limit switch 2 is wired to IN1. Set the dual channel mode for local input in the NE1A-series Controller to dual channel complementary.
Page 226 Dual Channel Complementary (1 pair). Muting Sequence 1. In figure 1 above, N.O. limit switch 1 is OFF and N.C. limit switch 2 is ON. In addition, the light curtain is not obstructed, so the Output Enable signal is ON.
Page 227 Muting Status and Output Enable signals are 3. When the workpiece moves to the right until it is no longer detected by the MS12, the muting status forced by the Override function will be cleared,...
Page 228: Enable Switch Monitoring (Enable Switch) Unit Ver. 1.0 Or Later
The Enable Switch function block monitors the status of the enable-switch device. The Output Enable signal is ON when the input from the monitored enable- switch device is active. The Output Enable signal is OFF when the input is not active or an error is detected in the function block.
Page 229 Section 8-5 Command Reference: Function Blocks In addition, if the enable-switch device is the type that outputs a grip signal and release signal, the device’s Grip Input and Release Input signal status can be monitored. The received Grip Input and Release Input signals do not affect the status of the Output Enable signal.
Page 230: Pulse Generator Unit Ver. 1.0 Or Later
The output pulse width will have an error equivalent to the cycle time. For example, if the cycle time is 7 ms and the pulse width is set to 100 ms, the output pulse will be from 93 to 107 ms.
Page 231 10 ms to 3 s in 10-ms increments 500 ms Off Pulse Time 10 ms to 3 s in 10-ms increments 500 ms The timer SV must be longer than the NE1A-series Controller’s cycle time. Timing Chart Idle to RUN...
Page 232: Counter Unit Ver. 1.0 Or Later
Network Configurator. The function counts the number of OFF-to-ON transi- tions in the input signal. To detect pulses in the input signal, the input pulse’s OFF time and ON time must be longer than the cycle time. ■ Counting Methods (Count Type) The Count Type can be set to Down counter or Up counter (decrementing or incrementing counter).
Page 233 Section 8-5 Command Reference: Function Blocks Set Parameters Parameter Setting range Default setting Reset Condition Auto Reset Manual Reset Manual Reset Count Type Down counter (decrementing counter) Down counter (decrementing counter) Up counter (incrementing counter) Counter 1 to 65,535 (count)
Page 234: Multi Connector Unit Ver. 1.0 Or Later
Default Maximum Number of outputs General Description This function can be used with Controllers with unit version 1.0 or later (including Controllers that support EtherNet/IP). The Multi Connector function outputs input signals (up to 8 inputs) to output signals (up to 8 outputs).
Page 235 Section 8-5 Command Reference: Function Blocks Optional Output Settings The number of outputs can be increased on the In/Out Setting Tab Page in the function block property dialog box. Parameter Setting range Default setting Number of inputs 1 to 8 Truth Tables ■...
Page 237: Other Functions
Access Control with Password ........
Page 238: Configuration Lock
The following occurs when the configuration lock is set. • The LOCK LED indicator on the front face of NE1A-series Controller lights yellow. (When unlocked, the indicator will flash yellow.) Lock LED indicator •...
Page 239: Reset
IMPORTANT When a Controller that supports EtherNet/IP is reset to its default settings, the IP address will be cleared and the IP address will then be acquired from the BOOTP server. If you wish to keep the same IP address, then select the Node...
Page 240: Reset Type And Ne1A-Series Controller Status
Unable to reset Able to reset Unable to reset Able to reset default configura- tion except to pre- serve the following parame- ters, and then emulate cycling power. Note Resetting is not possible after a safety I/O connection has been established.
Page 241: Access Control With Password
The NE1A-series Controller can register a password in its nonvolatile mem- ory. The password can be used to prevent unexpected or unauthorized access to the Controller from a person other than a user (i.e., a safety man- ager). No password is set by default; the user needs to register one.
Page 243: Operating Modes And Power Supply Interruptions
10-2 Behavior for Power Supply Interruptions ......10-2-1 Behavior in Voltage Drop ....... . .
Page 244: Ne1A-Series Controller Operating Modes
CONFIGURING Mode exists while waiting for the completion of configuration from the Network Configurator. The NE1A-series Controller switches to Con- figurating Mode when it is not yet configured after initialization has been com- pleted or when there is an error in the configuration data.
Page 245: Confirming The Operating Mode
Power is not supplied. : ON : Flashing : OFF Confirming with the Operating Mode Flag The user can determine whether the NE1A-series Controller’s operating mode is RUN Mode or not by checking bit 6 (Operating Mode Flag) of the Unit General Status.
Page 246: Functions Supported In Each Operating Mode
For details, refer to SECTION 9 Other Functions. (2) When the operating mode of the NE1A-series Controller is changed from RUN to IDLE, input data to the Master depends on the hold setting of the Standard I/O Area. For details, refer to SECTION 4 DeviceNet Communi- cations Functions and SECTION 5 EtherNet/IP Communications.
Page 247: Operating Mode Setting At Startup
IMPORTANT When the power supply is interrupted in IDLE Mode, the NE1A-series Control- ler will not start in RUN Mode at the next startup even though Automatic Exe- cution Mode is set and the configuration is locked. Make sure to turn OFF the power supply in RUN Mode.
Page 248 Test the system before starting actual opera- tion. (2) The maximum program execution delay is 20 seconds. Program execu- tion will start in 20 seconds even if all safety I/O communications have not started normally due to problems in the network, settings, or communica- tions.
Page 249: Behavior For Power Supply Interruptions
NE1A-series Controller will turn OFF the outputs. Low Power Supply Voltage for I/O Circuits If the power supply voltage for input drops to 85% of the rated voltage or lower when the power supply voltage for the internal circuit is normal, the NE1A- series Controller will continue operation but will stop refreshing inputs.
Page 251: Local I/O Response Time
11-1 Outline............11-2 Operational Flow and Cycle Time ....... . .
Page 252: Outline
The calculations shown here are assumed to satisfy the following conditions: • The configuration is correct. • The power has been turned ON, the SNC self-diagnostic function has been completed, and the NE1A-series Controller is in RUN Mode. • The necessary Safety Slaves have been added to the system.
Page 253: Operational Flow And Cycle Time
IMPORTANT For a Controller that supports EtherNet/IP, the maximum cycle time is 60 ms. If a cycle time of more than 60 ms is set, correct the connection settings and user applications and change the system configuration so that the cycle time...
Page 254: Startup Time
Note (1) With NE1A-series Controllers with unit version 2.0 (including Controllers that support EtherNet/IP), an online delay time of 5 s is added after the initialization has been completed to allow time for other devices to start. (2) After the initialization has been completed, the NE1A-series Controller checks for duplicated addresses on the DeviceNet network and then joins the network (i.e., goes online).
Page 255 ON, program execution is slower for unit version 2.0 (in- cluding Controllers that support EtherNet/IP) than for unit version 1.0. With a program in which a timer is started simultaneous with the start of NE1A-series Controller program execution, the time from when the power is turned ON until the timer times out is extended.
Page 256: I/O Refresh Cycle Time And Network Reaction Time
I/O reaction time. The I/O refresh cycle time is set to the optimum value for the configuration from among the following settings: 3.5, 4.0, 4.5, 5.0, 5.5, 6.0, or 6.5 ms. The I/O refresh cycle time can be checked from the Network Configurator.
Page 257 Page of the Edit Device Parameters Window. Note The minimum set for the EPI is either the cycle time of the Safety Network Controller or the cycle time of the Safety Slaves (always 6 ms), whichever is greater. The minimum setting for the EPI will therefore be affected if the cycle...
Page 258 I/O Refresh Cycle Time and Network Reaction Time Section 11-4...
Page 259: Reaction Time
Reaction Time 11-5 Reaction Time 11-5-1 Reaction Time Concepts The reaction time is the time required to stop machine operation in a worst- case scenario considering the occurrence of faults and failures in the safety chain. The reaction time is used to calculate the safety distance.
Page 260 = Result of Network Configurator calculation IMPORTANT If an output from a function block is fed back to the input side of the same function block, the cycle time of the NE1A-series Controller must be added to the reaction time for the safety chain.
Page 261 Controller cycle time = 4 ms I/O refresh cycle time = 4 ms The cycle time of the NE1A-SCPU02 is 6 ms and the I/O refresh time is 6 ms. The reaction time is obtained using the following equation: Reaction time (ms) = Switch reaction time...
Page 262 Section 11-5 Reaction Time The network reaction time will be 24 ms based on a safety connection EPI of 6 ms. The reaction time is obtained using the following equation: Reaction time (ms) = Switch reaction time + Safety I/O Terminal input reaction time...
Page 263 NE1A-SCPU01 cycle time = 7 ms I/O refresh cycle time = 3.5 ms The network reaction time will be 28 ms based on a safety connection EPI of 7 ms. The reaction time is obtained using the following equation: Reaction time (ms) = Switch reaction time...
Page 264 Section 11-5 Reaction Time Network reaction times #1 and #2 will be 24 ms each, based on a safety con- nection EPI of 6 ms. The reaction times are obtained using the following equa- tion: Reaction time (ms) = Switch reaction time...
Page 265: Troubleshooting
12-7 Errors When Changing Modes ........
Page 266: Error Categories
NE1A-series Controller errors can be categorized into the following three cat- egories: Nonfatal Errors The part where an error has occurred stops at each local I/O or safety I/O connection terminal and places it in the safety state. The Controller, however, continues in RUN Mode.
Page 267: Confirmation Of Error State
Confirmation of Error State 12-2 Confirmation of Error State Error details can be checked from the following two pieces of information: • LED indicator status on the front of the NE1A-series Controller • Reading the NE1A-series Controller’s error history using the Network...
Page 268: Indicator/Display Status And Corrective Actions For Errors
• Turn the power OFF and back ON and check operation. If the problem recurs, the NE1A- series Controller may be faulty. Note Not applicable to Pre-Ver. 1.0 Controllers. Applicable to unit version 1.0 or later (including Controllers that support EtherNet/IP).
Page 269 ON the power supply. address of because of fre- error • Make sure the baud rate is the quent data same for all nodes. errors.) • Make sure the cable lengths (main/branch) are not too long.
Page 270 Transmission See note Transmission Check the following points: Timeout timeout Node • Make sure the baud rate is the address of same for all nodes. error • Make sure the cable lengths (main/branch) are not too long. • Make sure the cable is not dis- connected or loose.
Page 271 OFF nal output). the input after the cause of the error has been removed. The error will be reset. If there is no fault with the wires, replace the unit. No LED Under Current...
Page 272 • Make sure the output signal terminal wire is not contacting the (Dual power source (positive side). Setting) • Make sure there is not a short circuit between output signal wires. flashing To recover from these errors, Target Short Circuit...
Page 273 Note (1) Not saved in Pre-Ver. 1.0 Controllers, but saved in Controllers with unit version 1.0 or later (including Controllers that support EtherNet/IP). (2) These functions are not supported by Pre-Ver. 1.0 Controllers. The error information is saved in Controllers with unit version 1.0 or later (including Controllers that support EtherNet/IP).
Page 274 Section 12-3 Indicator/Display Status and Corrective Actions for Errors Indicators/display Error history Cause Corrective actions Seven- Name Saved in segment nonvolatile display memory L9↔n4 --- Tag Data EtherNet/IP standard tar- Check the following points. Link Error get communications error • Make sure the same commu-...
Page 275: Error History
RAM of the Controller. The error history contains one record per error and can hold up to 100 records. If the error history table already contains 100 records, the oldest record is deleted and the new error data is stored.
Page 276 Reset Command addressed to the NE1A-series Controller to clear all or only specified variables to their default settings. (2) When the error history is read from the Network Configurator, the node address where the error occurred or the error response value is displayed as manufacturer-specific ALARM exception detail [7] 0x**.
Page 277 Section 12-4 Error History Time error occurred (total operation time) Error information...
Page 278: Error Information Details
Programming-related Errors Function Block Status Function Block Status Error An incompatible signal input was set as an input condition in the Error function block’s Set Parameters. Check the inputs entered in the function block or the program logic.
Page 279 After the latch input error time has passed, turn OFF the input when the cause of the error has been removed, and the error will be reset. If there is no fault with the wires, replace the unit.
Page 280: Ethernet/Ip-Related Error Information Details
Safety Output at safety output. • Make sure there is no overcurrent for the output. • Make sure the output signal wire does not have an earth fault. Short Circuit Detected at Short circuit was detected • Make sure the output signal wire is not contacting the power Safety Output at safety output.
Page 281 • Make sure the same communica- tions settings are used for each node. • Make sure cables are not discon- nected or bent. • Make sure power is supplied to the Originator. Link OFF error 03D3 Check the following points.
Page 282: Errors When Downloading
Once reset, download the parameters to all devices again. 3. Select Network – Property, and then click the Get from Network Button in the Net- work Number Field in the dialog box that appears. If there are multiple network num- bers, select one of these numbers to unify all to that network number.
Page 283 • One of the safety inputs in a dual channel setting is set as a standard input and the other has a different setting. • One of the safety inputs in a dual channel setting is set to Not used and the other has a different setting.
Page 284 There are open inputs or outputs in a function block used in the user program. Editor and check program. Click the Edit Button on the Logic Tab Page to open the logic and perform the following measures. • Connect the open inputs or outputs.
Page 285: Errors When Resetting
Check that the correct password is being used. The device cannot be accessed or 1. The device has just been reset or the power cycled and the device is not the device type or password is dif- ready for communications (i.e., not online with the NS indicator flashing or ferent.
Page 286: Errors When Changing Modes
Check that the correct password is being used. The device cannot be accessed or 1. The device has just been reset or the power cycled and the device is not the device type or password is differ- ready for communications (i.e., not online with the NS indicator flashing or ent.
Page 287: Connection Status Tables
If an error occurs when the NE1A-series Controller tries to establish a safety connection with a DST1-series Safety I/O Terminal or an NE1A-series Con- troller set as a Slave, the 7-segment display will display the error code “d6” or “d5.” If an error occurs during I/O communications, the 7-segment display will display the error code “dA”...
Page 288: Connection Status For Dst1 Series
• Is the network bandwidth allocation suitable? 01:0105 Configuration Owner Error The Safety Slave was configurated from a configuration tool or Safety Master at a different node address last time. Reset the Safety Slave to the default settings and download the device parameters again.
Page 289 The Safety Slave may not have been added to the network correctly. Check that the corresponding Safety Slave is online (i.e., the NS indicator is flashing green or lit green.) If the Safety Slave is not online, check the following items.
Page 290: Connection Status For The Ne1A-Series Controller (Safety Slave Function)
01:0109 Data Size Error The Safety Slave I/O size set to the NE1A-series Safety Slave and the size set under the Safety Master safety connection setting does not match. The Safety Slave I/O setting may have been changed, so delete then re-regis- ter the connections registered to the Safety Master.
Page 291 EPI has been set for a safety slave I/O. • To share one safety slave I/O on a Safety Slave with more than one Safety Master, make the EPI all the same and set the connection type to Multi-cast.
Page 292 The communications partner, a NE1A-series Controller that is functioning munications partner is in as a safety slave, is in IDLE Mode, so a safety I/O connection cannot be IDLE Mode established. Change the operating mode of the communications partner to RUN Mode.
Page 293: Maintenance And Inspection
13-1 Inspection ........... . 13-2 NE1A-series Controller Replacement.......
Page 294: Inspection
To use an NE1A-series Controller’s functions in the best condition, daily or periodical inspection must be performed. • Check that the NE1A-series Controller is used within the range of specifi- cations. • Check that installation conditions and wiring of the NE1A-series Control- ler are proper.
Page 295: Ne1A-Series Controller Replacement
• Check that there is no error in the new unit after replacement. • When returning the defective unit for repair, attach a sheet of paper to the unit describing in as much detail as possible the defect. Send the unit to the OMRON branch or sales office listed in the back of this operation manual.
Page 297: Appendix
S1: Emergency stop pushbutton S2: Reset Switch KM1 and KM2: Contactors M: Motor Note (1) Connect a 24-VDC power supply to terminals V0 and G0 (power supply terminals for internal cir- cuits). (2) This example shows the NE1A-SCPU01(-V1)(-EIP) Controller’s terminal layout.
Page 298 Appendix A Timing Diagram Emergency stop button Emergency stop button Limit switch turns ON. pressed. (ESTOP) pressed. ESTOP 11-12 ESTOP 21-22 More than More than 350 ms 350 ms Reset Feedback Idle to Programming Example...
Page 299 Appendix A Local Input and Test Output Setting Example Local Output Setting Example...
Page 300 S2: Limit switch (normal open contact) KM1 and KM2: Contactors M: Motor Note (1) Connect a 24-VDC power supply to terminals V0 and G0 (power supply terminals for internal circuits). (2) This example shows the NE1A-SCPU01(-V1)(-EIP) Controller’s terminal layout. Timing Diagram Safety gate opened.
Page 301 Appendix A Programming Example Local Input and Test Output Setting Example...
Page 302 Appendix A Local Output Setting Example...
Page 303 KM1, KM2, KM3, and KM4: Contactors M: Motor 11 21 12 22 KM3-NC KM1-NC KM4-NC KM2-NC Note (1) Connect a 24-VDC power supply to terminals V0 and G0 (power supply terminals for internal cir- cuits). (2) This example shows the NE1A-SCPU01(-V1)(-EIP) Controller’s terminal layout.
Page 304 Appendix A Timing Diagram Emergency stop button (ESTOP) pressed. 350 ms min. ESTOP Safety gate open Safety gate open RESET Safety Limit Switch S3 Limit Switch Safety Limit Switch S5 Limit Switch KM1,2 Feedback KM3,4 Feedback Idle to RUN : Maximum feedback time...
Page 305 Appendix A Local Input and Test Output Setting Example Local Output Setting Example...
Page 306 S2: Reset switch S3: Emergency stop pushbutton KM1 and KM2: Contactors M: Motor Note (1) Connect a 24-VDC power supply to terminals V0 and G0 (power supply terminals for internal circuits). (2) This example shows the NE1A-SCPU01(-V1)(-EIP) Controller’s terminal layout.
Page 307 Appendix A Timing Diagram Emergency stop button (ESTOP) pressed. 350 ms min. 350 ms min. ESTOP RESET KM1,2 Feedback Idle to RUN : Feedback time Programming Example...
Page 308 Appendix A Local Input and Test Output Setting Example Local Output Setting Example...
Page 309 White Black KM1-NC KM2-NC Note (1) Connect a 24-VDC power supply to terminals V0 and G0 (power supply terminals for internal circuits). (2) This example shows the NE1A-SCPU01(-V1)(-EIP) Controller’s terminal layout. Timing Diagram Emergency stop button (ESTOP) pressed. 350 ms min.
Page 310 Appendix A Programming Example Local Input and Test Output Setting Example...
Page 311 Appendix A Local Output Setting Example...
Page 312 Appendix 2: Calculated Values of PFD and PFH Calculated values of PFD and PFH for the NE1A-series Controller are given in the following tables. These val- ues must be calculated for the overall devices within the system to comply with the SIL required for application. A-2-1...
Page 313 Appendix A Appendix 3: Explicit Messages User-specified NE1A parameters can be read and written by sending explicit messages to the NE1A-series Controller. The NE1A-series Controller will process the received messages and return responses. This appen- dix describes the messages that are supported by the NE1A-series Controller.
Page 314 01 to 10 65 hex 1 byte Terminal Mainte- maintenance information for 00 hex: Total ON time nance Information the input (1 to 16) specified by mode the Instance ID. 01 hex: Contact operation counter mode Write Writes the monitor mode of...
Page 315 01 to 08 65 hex 1 byte Terminal Mainte- maintenance information for 00 hex: Total ON time nance Information the output (1 to 8) specified by mode the Instance ID. 01 hex: Contact operation counter mode Write Writes the monitor mode of...
Page 316 (unit: seconds) or contact 0000 0000 to FFFF Contact Operation operation counter (unit: opera- FFFF hex Counter tions) for the input (1 to 4) spec- (0 to 4,294,967,295) ified by the Instance ID. Write Writes the SV of the total ON 10 hex...
Page 317 Safety input = 05 0001 to 0100 Safety output = 06 hex (1 to 48) Address Specification Range: Local input: 0 to 4 Local output/test output: 0 or 1 Safety input: 0 to 511 Safety output: 0 to 511...
Page 318 01 to 28 65 hex 1 byte Terminal Mainte- maintenance information for 00 hex: Total ON time nance Information the input (1 to 40) specified by mode the Instance ID. 01 hex: Contact operation counter mode Write Writes the monitor mode of...
Page 319 01 to 08 65 hex 1 byte Terminal Mainte- maintenance information for 00 hex: Total ON time nance Information the output (1 to 8) specified by mode the Instance ID. 01 hex: Contact opera- tion counter mode Write Writes the monitor mode of...
Page 320 (unit: seconds) or contact 0000 0000 to FFFF Contact Operation operation counter (unit: opera- FFFF hex Counter tions) for the test output (1 to 8) (0 to 4,294,967,295) specified by the Instance ID. Write Writes the SV of the total ON 10 hex...
Page 321 Reads the cause for the normal 0E hex 01 to 10 6E hex 1 byte Error Information flag of the number (1 to 16) 00 hex: No error Cause specified by the Instance ID 01 hex: Invalid configu- being OFF (error).
Page 322 Read Reads the normal flag status 0E hex 01 to 05 hex 1 byte Output Normal of the number (1 to 8) speci- 08 hex 00 hex: Error Flag fied by the Instance ID. 01 hex: Normal Read Safety Read...
Page 323: Glossary
An acronym for Change of State. One of the connection types for I/O communi- cations in DeviceNet standard communications. For this connection type, data is sent after a set period of time elapses, just as for a cyclic connection, but data can also be sent when data changes or a data send request is received from the application.
Page 324 One of the connection types for I/O communications in DeviceNet standard communications. For a cycle connection, data is sent after a set period of time elapses. A cyclic connection enables sending data on a cycle that is different from the communi- cations cycle of the Master.
Page 325 The state of a component or device when the risk of human harm reduced to a permissible level. safety chain...
Page 327: Index
Enable Switch baud rate EPI (data expected packet interval) setting baud rate setting error detected during self-diagnosis baud rate switch error history error history saving area...
Page 328 I/O output tags LOCK LOCK LED logic functions lost password password power supply terminal for external input devices and test outputs power supply terminal for external output devices mode setting power supply terminal for internal circuits module status program capacity...
Page 329 Index remote I/O area subnet masks remote I/O area attributes supported function blocks Remote I/O Area Data Configuration synchronization time setting reset system configuration Reset Set Flip-Flop reset types resetting errors test output mode restart Test Output/Muting Lamp Status routing...
Page 331: Revision History
Revision History A manual revision code appears as a suffix to the catalog number on lower left corners of the front and back covers of the manual. Cat. No. Z906-E1-07 Revision code The following table outlines the changes made to the manual during each revision. Page numbers refer to the previous version.
Page 335 Tel: (1) 510-608-3400/Fax: (1) 510-744-1442 Shiokoji Horikawa, Shimogyo-ku, Kyoto, 600-8530 Japan OMRON ASIA PACIFIC PTE. LTD. Tel: (81) 75-344-7093/Fax: (81) 75-344-8197 No. 438A Alexandra Road # 05-05/08 (Lobby 2), Alexandra Technopark, Singapore 119967 Tel: (65) 6835-3011/Fax: (65) 6835-2711 Regional Headquarters OMRON (CHINA) CO., LTD.
