6-2

Menu Commands

The following tables describe the commands in the Logic Editor menus.
6-2-1

File Menu

Command
Apply
Import
Export
Print
Page Setup
Program Title
Exit
6-2-2

Edit Menu

Command
Cut
Copy
Paste
Delete
Properties
6-2-3

View Menu

Command
Object List
Status Bar
Tool Bar
6-2-4

Function Menu

Command
User EM
Monitoring
Jump New
Address
Select Pastes the destination of the jump address in the Workspace.
6-2-5

Page Menu

Command
Add Page
Delete Last
Page
Change Page
Title
100
Description
Temporarily saves the current program in the Configurator.
Reads a file saved using the Export Command.
Saves the current program to a file. The user can use the saved file
by importing it via another NE1A-SCPU01. The connection between
I/O tags, however, is not saved.
Prints the program.
Sets the page.
Sets the title and creator of the program. This information is added
when the program is printed.
Exits the Logic Editor.
Description
Cuts the selected function block and copies it to the clipboard.
Copies the selected function block to the clipboard.
Copies the function block on the clipboard to the Workspace.
Deletes the selected item.
Displays the property window of the selected function block.
Description
Display or hides the Object List.
Display or hides the status bar.
Displays or hides the toolbar.
Description
Sets the explicit message send function.
Monitors I/O tag values and signal states of all the connection lines
in the Logic Editor.
Creates a new jump address (jump source).
Description
Adds a new page after the last page.
Deletes the last page.
Changes the title of the selected page.
Section 6: Programming the Safety Network Controller
Online Offline
OK OK
OK OK
OK OK
OK OK
OK OK
OK OK
OK OK
Online Offline
OK OK
OK OK
OK OK
OK OK
OK OK
Online Offline
OK OK
OK OK
OK OK
Online Offline
OK OK
OK ---
OK OK
OK OK
Online Offline
OK OK
OK OK
OK OK
