Omron CX-PROGRAMMER V9 Operation Manual page 528

PART 3: CX-Server Runtime
GLOSSARY OF TERMS – CX-Server Runtime
Node number
Node
NSB
Offline
OLE
Online
Output
Packet
Parity
Path
Peripheral
Performance Monitor tool
Ping test
PLC Error component
PLC Memory component
PLC Setup component
PLC
Point
Port
Program
Program memory
Program mode
Programmable Read Only Memory
Project
PROM writer
PROM
Protocol
Rack
RAM
Registered IO Table
Root
Root group
CX-Server Runtime_Page 90
Number identifying the device located at a particular node on the network. The
number can be between 1 and 126, the maximum number of nodes available on an
OMRON network.
A position at which a device can be located on the network, consisting of a link unit
mounted to a device or PLC which in turn interfaces with a peripheral device or a
computer.
Network Service Board.
The status of a device when it is not being controlled by a computer (although it may
be physically connected to it).
Object Linking and Embedding. Used to transfer and share information between
Microsoft Windows based applications and accessories.
The status of a device when it is under the direct control of a computer.
The signal sent from a PLC to an external device.
A unit of information transmitted across the network containing source and
destination address information together with the actual data.
A type of validation check performed on transmitted information; data can be tested
for either even, odd, none, mark or space parity. The type of parity check involved is
indicated by the status of the parity bit.
The location of a file including the drive, directory name plus any subdirectories and
the file name together with its associated extension.
A device which aids system operation rather than being central to its functioning.
A CX-Server tool for monitoring communications throughput and for displaying CX-
Server's current performance level (i.e. a check to see if CX-Server is becoming
overloaded).
A standard Ethernet communications test.
This CX-Server component displays and manages PLC errors.
This CX-Server component allows the user to view, edit and monitor either channels
(words) or individual bits in areas of the PLC.
This CX-Server component permits the configuration of PLC settings.
Programmable Logic Controller.
A point is used to hold a value of a predefined type - Boolean, Integer, Text, etc. The
contents of a point may be controlled by an object or I/O mechanism such as DDE.
The contents of a point may control the action or appearance of an object, or be used
for output via an I/O mechanism.
A device connection point allowing data entry and exit.
A set of instructions which are performed by a computer or PLC.
An area of PLC memory reserved for the storage of programs.
PLC mode of operation during which the device can be programmed.
An area of memory which can be updated with programs and data only once after
manufacture; once this area has been written to, it can only be read, not modified.
OMRON configuration file inherited from the invoking application.
Refer also to CX-Server Project.
A device which writes the programs and data into PROM.
Programmable Read Only Memory.
A set of rules governing the transmission of data.
The apparatus to which a unit is fixed.
Random Access Memory.
The internal PLC table: this is the one used by the PLC when running, regardless of
the state of the actual hardware. It can be read and, for CV-series PLCs, written to by
the CX-Server software.
The highest level of a directory.
The highest level group in a CX-Server project.
OMRON
Revision 2.0
